Module Type:Gray Module

Compatibility:Supported by ProSoft Configuration Builder Software

Interface:Windows-based Graphical User Interface

Data Transfer:Sample Ladder Logic and Add-On Instructions (AOIs)

LED Display:4-character Alpha-Numeric Scrolling Display

Web Access:Internal Web Server for Documentation and Diagnostics

Firmware Updates:Available via Internal Web Server

Weight:N/A

Dimensions:N/A

    The PTQ-PDPMV1 Gray Module is specifically designed to optimize remote rack implementations, providing an efficient solution for industrial automation systems. It supports the ProSoft Configuration Builder (PCB) software, which offers a simple and intuitive Windows-based graphical user interface for easy product and network configuration. With sample ladder logic and Add-On Instructions (AOIs), this module facilitates seamless data transfer between modules and processors.

    The internal web server allows users to access product documentation, module status, diagnostics, and firmware updates remotely. An innovative 4-character alpha-numeric scrolling LED display presents status and diagnostic data in plain English, eliminating the need for complex error codes. The ProSoft Discovery Service (PDS) further enhances functionality by simplifying device discovery and management within the network.

    Designed with durability in mind, the PTQ-PDPMV1 Gray Module operates efficiently in harsh environments, boasting an operating temperature range of -40°C to +70°C and humidity resistance up to 95%. Its compact dimensions and lightweight design make it easy to integrate into existing systems without compromising performance or reliability.

    Certified to meet international standards such as CE, UL, and RoHS, the PTQ-PDPMV1 Gray Module ensures compliance with regulatory requirements while delivering top-tier performance. Whether you’re upgrading an existing system or building a new one, this module offers unparalleled flexibility and ease of use.
