PROSOFT PLX82-EIP-PNC

1. Product Overview

2. Technical Specifications

• Processor: Intel XScale PXA255
• Memory: 64 MB (including 64 MB NAND FLASH)
• Storage: 64 MB NAND FLASH, plus CompactFlash card support
• Communication Interfaces: 2 x 10/100 Mbit Ethernet (RJ45)
• Max PROFINET Devices: Up to 36 (including I/O modules, drives, HMIs, etc.)
• I/O Data Capacity: 3840 bytes input / 3840 bytes output
• Minimum RPI: 2 ms
• Power Supply: 24 VDC (10–36 VDC compatible), 400 mA (max 610 mA)
• Dimensions: 5.52 x 2.06 x 4.37 inches (14.01 x 5.24 x 11.09 cm)
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -10°C to 70°C
• Certifications: UL, CB, PROFINET, ODVA EtherNet/IP compliant

3. Key Features

• Multi-Protocol Support: Bridges EtherNet/IP and PROFINET for cross-vendor integration.
• High Performance: 2 ms minimum RPI for real-time control applications.
• Flexible Configuration: Configured via ProSoft Configuration Builder (Windows-based) with graphical interface and remote diagnostics.
• Large I/O Capacity: Up to 3840 bytes input/output for large-scale data transfer.
• Remote Maintenance: Remote configuration, firmware upgrades, and troubleshooting via Ethernet.
• Reliable & Secure: Industrial-grade design with support for 100% network redundancy (when used with ProLinx G2 series).

4. Structure and Components

Hardware

• CPU Module: Intel XScale processor for protocol conversion and data processing.
• Power Supply: Integrated wide-voltage power module.
• Ethernet Ports: Two RJ45 ports for connecting EtherNet/IP and PROFINET networks.

Software

• ProSoft Configuration Builder: Graphical tool for gateway configuration.
• ProSoft FDT Configuration Manager: For remote maintenance and monitoring.

5. Application Areas

• Cross-vendor Automation Integration: Connect Rockwell PLCs with Siemens or other PROFINET-based controllers.
• Field Device Integration: Integrate third-party I/O, drives, and sensors into Rockwell systems.
• Process Control Systems: Link process controllers and actuators from different suppliers.
• Safety System Integration: Connect safety modules using different protocols in Safety Instrumented Systems (SIS).

Maintenance & Diagnostics

• LED Indicators: Check power, network, and error LEDs to quickly assess device status.
• Remote Diagnostics: Use FDT Configuration Manager to view “Last Error” or “Alarm” logs.
• Firmware Upgrades: Regularly check the ProSoft website for updates and upgrade via USB or Ethernet.
• Backup Configuration: Export and save current configuration files before making major changes.

————————————————————————————————-
