1. Overview

2. Specifications

• Communication Speed: Supports multiple baud rates for PROFIBUS DPV0/V1.
• Power Requirements: Input voltage range of 10–36V DC, with a power consumption of approximately 2.04W.
• Operating Temperature: -20°C to 70°C.
• Interfaces: Dual Ethernet ports supporting DLR ring topology or embedded switch functionality.
• Status Monitoring: Provides detailed status information such as baud rate, node address, response time, and more.

3. Product Features

• Two-Mode Support: Configurable as either Master or Slave mode for flexible network integration.
• Protocol Conversion: Supports EtherNet/IP DLR topology and Modbus (TCP/IP or serial) for multi-network connectivity.
• Diagnostic Tools: Built-in PROFIBUS DP packet capture tool reduces network debugging time significantly.
• Advanced Functions: Supports FDT/DTM technology for slave device configuration and asset management via Device Type Managers.

4. Structure and Components

• Housing: IP20-rated, NEMA/UL open-style design for efficient heat dissipation.
• Hardware Layout: Equipped with 6 LED indicators for diagnostics and supports up to 4 EtherNet/IP Class 1 I/O connections.
• Network Interfaces: Dual Ethernet ports with DLR ring support or embedded switch capability, offering flexible installation options.

5. Application Areas

• Cross-Segment Data Exchange: Enables sharing of process data and diagnostics between PROFIBUS DP and EtherNet/IP networks.
• Multi-Protocol Environments: Serves as a bridge in factory settings using PROFIBUS, EtherNet/IP, and Modbus.
• Network Debugging: Utilizes the built-in PROFIBUS packet capture for troubleshooting and network analysis.

6. Installation and Maintenance

• Installation: Accepts 10–36V DC power input with a 3-pin terminal block compatible with 24–18 AWG wires.
• Configuration Tools: Parameters and firmware can be managed using ProSoft’s configuration utilities such as the PLX50 Configuration Utility.
• Maintenance: Status monitoring and diagnostics are available via a built-in web server or FDT/DTM management tools, providing detailed operational statistics to assist maintenance tasks.
