PROSOFT PLX51-HART-4I Controller Module

The PLX51-HART-4I solves the communication gap between traditional process instruments (such as pressure and flow transmitters) and modern Ethernet-based control systems.

PROSOFT PLX51-HART-4I

1. Product Overview

The PLX51-HART-4I solves the communication gap between traditional process instruments (such as pressure and flow transmitters) and modern Ethernet-based control systems. It converts HART device data into Ethernet-compatible protocols, allowing PLCs, SCADA systems, and host computers to directly read and control field instruments.

2. Key Specifications

Communication Channels

4 independent HART channels

Electrical Characteristics

Resolution: 12-bit ADC
Input impedance: 247.5 Ω
Accuracy: < 0.15% calibrated, < 0.30% uncalibrated
Measuring range: 0 to 22 mA
Current limiting: 34 mA

Network Interface

Physical: RJ45 port, compatible with Cat5 STP/UTP cables
Protocols: EtherNet/IP, Modbus TCP/IP, DNP3 (TCP/UDP), PCCC (AB-ETH)
Connection capacity: Up to 20 ARP/TCP connections, 10 CIP connections

3. Main Features

Multi-drop Communication: Supports up to 4 HART devices in multi-drop mode, reducing wiring costs.
Direct Access & Customization: Allows custom HART messaging for direct device access and advanced diagnostics.
Easy Integration: Works with the ProSoft PLX50 Configuration Utility and supports hot-swapping for simplified maintenance.
Broad Compatibility: Interoperable with various HART-enabled instruments, including 4-20 mA and 0-20 mA devices.

4. Structure & Components

Front Panel

6 LED indicators (Ok, Eth, Ch 0–Ch 3) for monitoring device and channel status.

Terminal Area

Power terminals
Earth ground terminal
4 channel terminals (Channel 0–3) for connecting field instruments

5. Typical Applications

Process Control: Connect pressure, temperature, and flow transmitters to host systems.
Industrial Automation: Integrate HART instruments with Allen‑Bradley/Rockwell PLCs.
SCADA Systems: Enable remote data acquisition and monitoring via DNP3.

————————————————————————————————-
