PROSOFT PLX31-EIP-PND

1. Overview

2. Specifications

• Data Capacity: Supports up to 1440 bytes of input and output data, suitable for most industrial applications.
• RPI (Requested Packet Interval): Minimum 10 ms RPI for high‑speed data updates.
• Power & Environment: Operates on 24 VDC power and features a wide operating temperature range, as well as shock and vibration resistance for harsh industrial conditions.
• Certifications: Complies with ATEX, CE, UL, and other international safety standards, ensuring reliability across diverse industrial environments.

3. Key Features

• Bidirectional Communication: Enables I/O data exchange between EtherNet/IP™ and PROFINET® IO controllers.
• Multiple I/O Connections: Supports multiple I/O connections with independent RPI settings for different data types, optimizing network bandwidth.
• Easy Integration: Includes a built‑in EDS (Electronic Data Sheet) for simple integration with Rockwell Automation PLCs (such as Allen‑Bradley®), requiring no ladder logic programming.
• Simplified Configuration: Compatible with ProSoft Discovery Service for easy IP address management and configuration via PC software.

4. Structure & Interfaces

• Interfaces: Provides Ethernet RJ45 ports for EtherNet/IP™ and PROFINET® IO connections.
• Storage: Includes an SD card slot for configuration file storage and backup, simplifying on‑site maintenance.

5. Application Areas

• Cross‑Protocol Communication: Ideal for systems where Allen‑Bradley® (EtherNet/IP™) controllers need to communicate with Siemens or other PROFINET®‑based devices.
• Data Acquisition: Collects sensor data from PROFINET® devices and transmits it to EtherNet/IP™ controllers for advanced control and analysis.
• Diagnostics & Monitoring: Different RPIs can be configured for high‑frequency diagnostic data, improving system reliability and maintainability.

6. Installation & Maintenance

• Installation: Typically mounted in control cabinets or field enclosures. Ensure adequate ventilation for heat dissipation.
• Maintenance: Supports online firmware upgrades and parameter adjustments. Remote monitoring and configuration are available via ProSoft Discovery Service or a web interface, reducing on‑site maintenance efforts.
