The PROSOFT MVI69L-MBTCP is a cost‑effective Modbus TCP/IP Lite communication module designed for Rockwell Automation CompactLogix L2 PLCs. Ideal for small‑scale, budget‑sensitive applications requiring Modbus TCP connectivity.
1. Product Overview
Product Positioning: Modbus TCP/IP Lite communication module for the CompactLogix L2 platform. Primary Function: Bridges communication between CompactLogix PLCs and Modbus TCP/IP‑enabled devices, supporting both Client (Master) and Server (Slave) modes. Typical Applications: Cost‑sensitive environments with moderate I/O data requirements.
2. Key Specifications
CPU Compatibility: Designed exclusively for CompactLogix L2 controllers. I/O Data Capacity: 240 words (equivalent to 240 16‑bit integers). Connection Capacity: Supports up to 10 Server (Slave) and 10 Client (Master) connections simultaneously. Configuration: Includes a simplified configuration file and instruction set for faster setup. Network Interface: Features a dedicated Ethernet port for module diagnostics and communication.
3. Product Features
Cost‑Effective Solution: As a Lite version, it offers lower hardware and maintenance costs. Simplified Commissioning: Comes with a streamlined configuration file and instruction set to reduce setup complexity. High Integration: Installs directly on the CompactLogix PLC backplane and is configured via ProSoft Configuration Builder (PCB). Flexible Communication: Supports Multi Client / Multi Server communication for versatile connectivity.
4. Structure and Components
Hardware Module: Standard 1U CompactLogix expansion module. Software Tools: Requires ProSoft Configuration Builder (PCB); configuration files are typically saved as .L5X and downloaded to PLC tags. Interfaces: Includes an Ethernet port for Modbus communication and a backplane connection for PLC integration.
5. Application Areas
Industrial Automation: Connects PLCs with Modbus‑compatible field devices such as temperature controllers, meters, and sensors. Process Control: Provides an economical solution for industries like oil & gas, pulp & paper, and pharmaceuticals that need to communicate with legacy Modbus equipment. Data Acquisition: Integrates Modbus device data into Rockwell control systems for real‑time monitoring.
6. Installation and Maintenance
Installation: Plug‑in module that fits directly into a CompactLogix PLC backplane slot. Configuration: Set up parameters and I/O mapping using ProSoft Configuration Builder. Diagnostics: Built‑in diagnostic capabilities accessible via the dedicated Ethernet port or PLC program. Maintenance: Focuses on software configuration updates and network connectivity checks.
————————————————————————————————-
