PROSOFT MVI69E

1. Product Overview

2. Specifications

• Baud Rate: Supports 115200, 230400, 460800, 921600, 1843200, and other rates to accommodate various network bandwidth requirements.
• Data Bits: 8 bits.
• Stop Bits: 1 bit.
• Parity: None, even, and odd parity supported.
• Operating Temperature: -20°C to 70°C, suitable for harsh industrial conditions.
• Communication Interface: RJ45 Ethernet port supporting TCP/IP protocol.
• Power Supply: 24VDC, compatible with common industrial power systems.
• Enclosure Protection: IP65-rated housing for dust and water resistance, ideal for outdoor and high‑humidity environments.

3. Key Features

• Modbus TCP/IP Support: Optimized for Modbus TCP/IP networks to ensure stable and efficient data transmission.
• Multi‑Data Type Support: Capable of handling various data types to meet the demands of complex industrial control systems.
• Easy Installation and Configuration: Compact size and lightweight design (approximately 0.5 kg) for quick integration into existing systems.
• Industrial‑Grade Reliability: Features anti‑interference design and lightning protection for continuous, stable communication.
• Security: Some models support RADIUS for advanced authentication and encryption, ensuring network security.

4. Structure and Components

• Communication Interface: RJ45 Ethernet port for connecting to industrial networks.
• Processor and Memory: Built‑in ARM Cortex processor with Flash and RAM for powerful computing and data storage.
• Power Supply Module: 24VDC input for stable power delivery.
• I/O Ports: Some models include analog and digital I/O channels for direct connection to field devices.

5. Application Areas

• Factory Automation: Connects sensors, actuators, PLCs, and host systems for data acquisition and control.
• Building Automation: Used in intelligent building management systems for energy management and equipment monitoring.
• Power Systems: Enables data collection and monitoring of electrical equipment to ensure grid safety.
• Water Treatment: Monitors water quality parameters and equipment status in water supply and wastewater treatment plants.
• Transportation: Applied in traffic signal control and monitoring systems.

6. Installation and Maintenance

• Environmental Requirements: Install in a dust‑free and dry environment. The IP65 rating provides protection against moisture and corrosive gases.
• Wiring Standards: Use shielded Ethernet cables compliant with industrial standards to minimize electromagnetic interference.
• Power Management: Ensure a stable 24VDC power supply to prevent damage from voltage fluctuations.
• Regular Inspection: Check connection status and operating temperature periodically. Keep the module clean to maintain proper heat dissipation.
• Firmware Updates: Stay updated with the latest firmware releases from PROSOFT to access new features and security patches.
