I/O Size:0/120/240 – 16 bit integers

Communication Parameters:{“Baud Rate”:”110 to 115K baud”,”Stop Bits”:”1 or 2″,”Data Size”:”7 or 8 Bits”,”Parity”:”None, Even, Odd”,”RTS Timing Delays”:”O to 65535 milliseconds”}

Floating Point Data:Supported, including configurable support for Enron, Daniel® and other implementations

Protocol Compatibility:Modbus Master/Slave

    The Prosoft MVI69E-MBTCP module is a powerful addition to your industrial automation arsenal, offering unparalleled efficiency in communication protocols. This ASCII module is specifically designed for CompactLogix processors, ensuring compatibility with the latest versions of 1769 I/O buses (version 16 and above), making it a versatile choice for various applications.

    With its add-on instruction feature, you can create User Defined Types (UDTs), which provide logical definitions for input/output (I/O), status, and control data. This simplifies the process of managing complex operations within your control system, leading to increased productivity and streamlined workflows.

    Enhanced diagnostic data is available in RSLogix 5000 controller tags, allowing for real-time monitoring and decision-making based on the health of individual nodes. This feature ensures proactive maintenance and operational efficiency.

    Featuring licensed backplane technology, the module is manufactured under exclusive license from Rockwell Automation, guaranteeing high-speed data transfer between the MVI69 module and CompactLogix or MicroLogix processors. The modular design allows for seamless integration into existing systems, with a sample ladder logic included for ease of setup.

    For those requiring precision and reliability, the Prosoft MVI69E-MBTCP supports floating point data movement across various implementations, including Enron, Daniel®, and others, ensuring compatibility and accuracy in critical applications. This module is an indispensable tool for enhancing the performance of your automation systems.
