PROSOFT MVI69-MCM

1. Overview

2. Key Features

• Multi-Protocol SupportSupports both Modbus RTU and ASCII protocols, and can be configured as either Master or Slave.

• Enhanced Data TransferEnables floating-point data transfer and supports the Enron variant of the Modbus protocol.

• Powerful Configuration SoftwareConfigured via ProSoft Configuration Builder (PCB) software, simplifying network setup and management.

• Platform CompatibilityDesigned specifically for CompactLogix and MicroLogix platforms, and installs directly on these processors.



3. Package Contents

• MVI69-MCM ModuleThe main unit providing Modbus communication interfaces.

  • RS232 Null Modem cable
  • DB9-to-RJ45 adapter cable
  • DB9 female-to-screw terminal adapter for RS422/RS485 networks
    Communication Cables
• Software and Documentation
  • ProSoft Solutions CD
  • Sample programs, utilities, and comprehensive documentation


4. Typical Applications

• Industrial AutomationConnects various Modbus-compatible sensors, actuators, and instruments to Rockwell PLC systems.

• Process ControlIdeal for process automation systems requiring integration with legacy Modbus networks.

• System IntegrationServes as a protocol bridge in multi-vendor or multi-protocol automation systems, enabling efficient data sharing across the network.

5. Installation and Maintenance

• The module mounts directly on the backplane of CompactLogix or MicroLogix processors.
• Ensure compatibility with the target processor and use the supplied cables for network connections.

• Configuration is performed using ProSoft Configuration Builder (PCB) software.
• Typical steps include setting jumpers, installing the module, configuring the RSLogix project, and importing ladder logic.
• Key configuration items include module addressing, communication parameters (baud rate, parity, etc.), and read/write register ranges.

• Global technical support is available, along with technical manuals and online resources.
• Periodically check network connection status, communication diagnostics, and firmware updates to ensure long-term communication stability.
