PROSOFT MVI56-GEC

The ProSoft MVI56-GEC is a high-reliability, multi-functional interface module designed for demanding industrial control and data acquisition. Its modular, compact, and DIN-rail-mountable design ensures stable performance in harsh environments such as power plants, metallurgical works, petrochemical facilities, and transportation systems, with an operational temperature range from -40°C to +85°C.

Parameter Overview

• Power Supply: 24 VDC (±10% tolerance).
• Operating Temperature: -40°C to +85°C.
• Storage Temperature: -55°C to +125°C.
• Communication Interfaces: RS-485 (Modbus RTU/TCP), CANopen, optional Ethernet/IP.
• I/O Capabilities:
• 8 Digital Inputs (DI)
• 8 Digital Outputs (DO)
• 4 Analog Inputs (0-10 V / 4-20 mA)
• 2 Analog Outputs (0-10 V / 4-20 mA)
• Isolation: All I/O and power terminals feature optocoupler/magnetic isolation (≥2500 VAC).
• Enclosure: IP40 rated; corrosion-resistant steel or aluminum alloy housing for indoor cabinet use.

Product Features

• Modular & Hot-Swappable: Standardized slot design supports plug-and-play module replacement or upgrades without system downtime.
• High Reliability: Built with industrial-grade components and comprehensive protection (overvoltage, overcurrent, short-circuit, reverse polarity).
• Integrated Protocol Support: Compatible with Modbus, CAN, and Ethernet for easy integration with PLCs and supervisory systems.
• Enhanced Diagnostics: Status LEDs, fault logging, and remote query capabilities enable quick troubleshooting.
• Space-Saving Design: Compact 56mm DIN-rail form factor optimizes control cabinet space.

Structure and Components

• Power Module: Converts 24 VDC input, provides EMC filtering, and monitors power stability.
• Digital I/O Module: 8 isolated digital inputs and 8 relay outputs; each channel configurable with pull-up/down resistors.
• Analog I/O Module: 4 input and 2 output channels supporting 0-10 V or 4-20 mA signals; features software calibration.
• Communication Interface Board: Manages physical layer connections and protocol processing for RS-485, CAN, and Ethernet.
• Mounting Bracket: DIN-rail base with anti-loosening bolts and clearly labeled terminal blocks for easy installation.

Application Fields

• Power Systems: Substation protection, distribution automation, generator monitoring.
• Industrial Automation: CNC machine monitoring, robotic I/O expansion, PLC fieldbus integration.
• Building & Transportation: Elevator control, subway signaling, smart building energy management.
• Process Industries: Chemical, petroleum, and metallurgy for precise sensor data acquisition and actuator control.
