ProSoft MVI56-ADM

1. Overview

2. Key Technical Specifications

Power Requirements

• 5.1V DC (5V power supply): 800 mA (high-current supply)
• 24V DC (24V power supply): 3 mA

Temperature Range

Communication Interfaces

• Two independently isolated serial ports (RS-232/422/485)
• Baud rate range: 300 bps to 115.2 kbps
• Data buffering: Up to 4 KB

Physical Dimensions

3. Product Features

• Multi-protocol Support: Compatible with industrial communication protocols including Modbus RTU/ASCII and DF1, enabling connection with devices of various brands and types.
• High Reliability: Certified with CE, UL, and cUL approvals, suitable for harsh industrial environments.
• Diagnostic Capabilities: Equipped with LED indicators and software diagnostic functions that display real-time communication status and error codes, facilitating quick troubleshooting.
• Flexible Memory Configuration: Supports user-defined register mapping with fully customizable memory usage, adapting to diverse application scenarios.

4. Structure and Components

• Power Module: Converts power from the PLC backplane to the 5.1V or 24V required by the module.
• Communication Interface Module: Integrates two RS-232/422/485 serial ports for connecting external devices.
• CPU Processing Unit: Handles core functions such as protocol conversion, data mapping, and error detection.
• Memory Module: Includes RAM (for data buffering) and Flash (for firmware storage).

5. Application Areas

• Industrial Automation: Connects PLCs, HMIs, and SCADA systems of different brands to achieve seamless data interoperability.
• Data Acquisition and Monitoring: Links field sensors and instruments to collect on-site data and transmit it to monitoring centers.
• Energy and Water Treatment: Used for monitoring and controlling the operational status of equipment such as water pumps, valves, and generators.
• Oil & Gas and Remote Control: Connects telemetry devices in oil and gas exploration and production, and supports communication for remote sites.
