PROSOFT MVI56-104S Communication Module

The MVI56‑104S is a high‑performance communication module in the PROSOFT product line. It features a compact 1‑slot (1U) design and provides dedicated support for the IEC 60870‑5‑104 protocol.

PROSOFT MVI56-104S

1. Overview

The MVI56‑104S is a high‑performance communication module in the PROSOFT product line. It features a compact 1‑slot (1U) design and provides dedicated support for the IEC 60870‑5‑104 protocol. The module enables bidirectional data exchange between ControlLogix controllers and SCADA systems by converting internal ControlLogix data into a format compatible with IEC 60870‑5‑104.

2. Key Specifications

  • Form Factor: 1U single‑slot design, compatible with the 1756 ControlLogix backplane.
  • Protocol Support: IEC 60870‑5‑104.
  • Data Capacity: Supports mapping up to 10,000 16‑bit registers (equivalent to 5000 AI/DI points).
  • Interface: 10/100 Ethernet (RJ45) port with TCP/IP connectivity.

3. Product Features

  • High Performance: Hardware‑accelerated architecture for fast data acquisition and transmission.
  • Industrial Reliability: Rugged design suitable for harsh industrial environments.
  • Flexibility: User‑configurable data mapping to accommodate diverse control logic requirements.

4. Structure and Components

The MVI56‑104S integrates a high‑performance microprocessor and memory, along with diagnostic LED indicators. It connects electrically and data‑wise with the ControlLogix CPU through the backplane and is fully compliant with Allen‑Bradley industry standards.

5. Typical Applications

  • Power Systems: Grid dispatch, substation monitoring.
  • Water and Wastewater: Water treatment automation, sewage monitoring.
  • Oil & Gas: Production process monitoring, equipment condition monitoring.

6. Installation and Maintenance

  • Installation: Simply insert the module into an available slot in the ControlLogix chassis and connect a standard Ethernet cable.
  • Maintenance: The module supports hot‑swapping and features LED status indicators. Configuration and diagnostics can be performed online via RSLogix 5000.

————————————————————————————————-
