PROSOFT C19M10-80-002

Product Overview

Specifications

• Model: PROSOFT C19M10-80-002
• Cable Type: 2ft LMR
• Connector Type: RP-SMA (Reverse Polarity SMA)
• Structure: N PL PLC (N-type connector with waterproof plug)
• Rated Current: 195mA
• Voltage Rating: 5.1VDC (commonly used for low-voltage DC communication systems)

Key Features

• Low Smoke Zero Halogen (LSZH): Complies with strict fire safety standards. It does not emit toxic gases or corrosive halogen substances even under high-temperature conditions or in case of fire, minimizing potential hazards in industrial sites.
• High Durability: Made of industrial-grade cable materials, it resists mechanical wear, oil contamination, and chemical corrosion, adapting to the tough operating environment of industrial facilities.
• Secure Connection: Equipped with RP-SMA reverse polarity connectors, it maintains stable and firm connections even in high-vibration or shock-prone scenarios, preventing signal interruption.
• Electromagnetic Compatibility (EMC): Features enhanced anti-electromagnetic interference capability, making it suitable for the complex electromagnetic environment of industrial fields.

Structure and Components

• Outer Sheath: Adopts LSZH material to provide mechanical protection and fire-retardant performance, ensuring safety and longevity.
• Conductor: Contains 1 solid copper conductor (non-twisted) inside, serving as a stable pathway for current transmission.
• Insulation Layer: Wrapped around the conductor to ensure electrical safety and prevent leakage or short circuits.
• Connectors: Equipped with RP-SMA connectors at both ends, enabling fast and convenient plug-and-play operations.

Application Areas

• PLC Communication: Establishes connections between Allen-Bradley Micro800 series PLCs and field devices, facilitating efficient data exchange.
• Sensor Networks: Connects ProSoft communication modules to distributed sensors (such as temperature sensors and pressure sensors) for real-time data collection.
• Industrial Automation: Used for low-voltage signal transmission in automated systems, including robotics, CNC machine tools, and packaging production lines.
• Fieldbus Communication: Compatible with ProSoft fieldbus communication protocols such as DeviceNet and Modbus, supporting seamless integration into industrial control networks.

Installation and Maintenance

Installation Precautions

• Avoid Twisting: Do not over-bend the cable during installation. The recommended minimum bending radius should not be less than 10 times the cable diameter.
• Secure Connection: When connecting the RP-SMA plug, tighten it clockwise to the proper position to prevent signal loss caused by loose connections.
• Protective Measures: In areas with sharp metal edges or high temperatures, use cable protective sleeves to provide additional protection for the cable.

Maintenance Recommendations

• Regular Inspection: Periodically check the cable for signs of damage, aging, or loose connectors to ensure continuous and stable operation.
• Waterproof Check: Although the N PL PLC connector has waterproof performance, for outdoor or humid environment applications, regularly inspect the integrity of the sealing ring to prevent water ingress.
• Cleaning: If dust or oil stains are found on the interface, clean it with a dry soft cloth. Avoid using highly corrosive cleaning agents that may damage the connector or cable sheath.
