PROSOFT 5201-DFNT-DH48 Industrial Ethernet

An industrial Ethernet (EtherNet/IP) communication gateway that enables seamless data exchange between EtherNet/IP networks and other fieldbuses such as Modbus, Profibus, and more.

PROSOFT 5201-DFNT-DH48

1. Overview

Product Name: ProSoft 5201-DFNT-DH48

Product Positioning:An industrial Ethernet (EtherNet/IP) communication gateway that enables seamless data exchange between EtherNet/IP networks and other fieldbuses such as Modbus, Profibus, and more.

Series Background:The 5201-DFNT-DH48 is part of the ProSoft 5201 series of communication gateways, which are well-known for their high reliability and flexible protocol conversion capabilities. These gateways are widely used in industrial automation systems across various industries.

2. Parameters

Operating Voltage: 24V DC or 120/240V AC
Communication Speed: 10/100 Mbps Ethernet

Protocol Conversion:

Between EtherNet/IP and Modbus RTU/ASCII
(Configuration based on the DH48 suffix)

Interfaces:
- RJ45 Ethernet port
- DB-9 serial port (RS-485 / RS-232)
- Digital and analog I/O interfaces for PLC connection

3. Key Features

High Reliability
Industrial-grade design with a wide operating temperature range and robust protection, suitable for harsh industrial environments.
Easy Configuration
Equipped with a dedicated PC configuration tool (such as ProSoft Configurator), supporting one-click setup and comprehensive diagnostics.
Flexibility
Supports flexible mapping between multiple communication protocols, allowing users to customize data mapping according to specific application requirements.

4. Structure and Components

Main Control BoardIntegrates CPU and memory chips to handle protocol conversion logic and data processing.
Communication ModulesIncludes Ethernet interface cards and serial/fieldbus interface cards for connecting different networks.
Power Supply ModuleProvides isolated power to ensure electrical safety and stable communication performance.

5. Installation and Maintenance

InstallationTypically mounted on a DIN rail inside control cabinets or fixed via brackets. Proper protection against water and dust should be ensured for all interfaces.
MaintenanceRegularly check connection cables and power supply. Use ProSoft’s diagnostic tools to monitor gateway status, detect faults, and ensure long-term stable operation.

————————————————————————————————-
