ATLAS PF4002-G-EIP-HW
1. Product Overview
The PF4002-G-EIP-HW is a specific hardware configuration within the Atlas Copco PF4000 series of controllers (EIP stands for EtherNet/IP communication protocol). It is a control and monitoring unit designed for electric assembly tools, featuring a graphical user interface that facilitates easy setup and monitoring for operators.
___________________________________________________________________________________________________________________________
2. Parameters & Technical Specifications
|
Parameter Category
|
Details
|
|---|---|
|
Communication Protocol
|
Supports EtherNet/IP (EIP); optional Open Protocol, PROFINET, USB, RS232, etc.
|
|
Power Supply Requirements
|
Suitable for single-phase 110V or 230V AC power supply, with automatic power voltage sensing.
|
|
Tool Compatibility
|
Compatible with Atlas Copco Tensor series electric tightening tools.
|
|
User Interface
|
Equipped with an advanced graphical interface, supporting real-time data recording and traceability analysis.
|
|
Installation Requirements
|
Compact design, suitable for installation in industrial control cabinets.
|
___________________________________________________________________________________________________________________________
3. Product Features
- Multiple Tightening Strategy Support: Supports angle control, torque control, and combined control strategies.
- Highly Scalable: Supports multi-channel expansion and automatic tool identification, adapting to complex processes and multi-task operation scenarios.
- Real-Time Data Traceability: Features real-time data recording function, facilitating quality control and process optimization.
- Advanced Communication Capability: Built-in EtherNet/IP communication module, supporting high-speed industrial network communication.
- Safety & Reliability: Equipped with anti-static discharge (ESD) design, along with complete safety warnings and maintenance guidelines.
___________________________________________________________________________________________________________________________
4. Structure & Composition
- Main Unit: Core control unit integrating processor, memory, and communication module.
- Display/Operation Panel: Used for displaying real-time data and setting parameters.
- Input/Output Interfaces: Including Ethernet (EIP), USB, RS232 interfaces, etc., for connecting external devices or networks.
- Tool Connection Interface: Used for connecting Atlas Copco electric tightening tools.
___________________________________________________________________________________________________________________________
5. Application Fields
- Automotive Manufacturing: Assembly of key components such as engines, gearboxes, and chassis.
- Aerospace Industry: High-precision tightening of bolted connections for aircraft structural components.
- Electronic Product Assembly: Assembly lines requiring multi-station process control and traceability.
- High-Reliability Industrial Connection Scenarios: Such as electrical equipment production.
————————————————————————————————-
