Omron CP1E-E20SDR-A Analog Signal Processing & Digital Logic Control Module

The Omron CP1E-E20SDR-A is a high-performance PLC module designed for precise analog signal processing and digital logic control applications in industrial environments. It features built-in USB, RS-232C, and RS-485 communication ports, allowing for easy integration with computers and other devices. The module supports input interrupts and can expand functionality with additional I/O units.

Tag：CP1E-E20SDR-A, CP1E-E20SDR-A Controller, CP1E-E20SDR-A PLC, CP1E-E20SDR-A PLC Motor, OMRON, OMRON DCS

Number of Ports:3 (USB, RS-232C, RS-485)

Input Current:5 mA typical (24 VDC)

Rated Voltage:24 VDC (20.4 to 28.8 VDC)

Leakage Current:0.1 mA max.

I/O Common:PNP

Depth Reduction:20 mm (with RS-232C connectors)

The Omron CP1E-E20SDR-A module is part of the new lineup of CP1E CPU units from Omron. Featuring three built-in ports: USB, RS-232C, and RS-485, this module is designed for seamless integration with computers through commercially available USB cables. Its compact design reduces the depth by 20mm when equipped with RS-232C connectors, making it ideal for space-constrained installations.

With the ability to add I/O, analog I/O, or temperature inputs via expansion units or I/O units, this module provides flexibility and scalability for various industrial control applications. The inclusion of input interrupts enhances the responsiveness and accuracy of the system, making it a top choice for demanding environments.

Designed for reliability and efficiency, the CP1E-E20SDR-A operates within a rated voltage range of 24 VDC (20.4 to 28.8 VDC) and supports a leakage current of up to 0.1 mA maximum, ensuring stable operation even under challenging conditions. Its PNP internal I/O common ensures compatibility with a wide range of sensors and devices.

Omron CP1E-E20SDR-A
