Number of Channels:16

Analog Input Range:-10 V to +10 V

Data Rate:100 kS/s per channel

Resolution:12-bit

Power Supply:±15 V

Operating Temperature:-40°C to +70°C

Dimensions:4U, 9.3 inches (W) x 1.1 inches (H)

Weight:Approximately 0.7 kg

    Introducing the NI PCI-6229, the next generation of data acquisition modules designed to meet the stringent demands of industrial automation. This compact, yet powerful module offers unparalleled flexibility and precision, making it an ideal choice for complex measurement tasks across various industries.

    Equipped with 16 high-resolution analog input channels, the PCI-6229 excels at capturing precise voltage signals from sensors and transducers. Its high-speed sampling rate ensures that even the fastest-changing signals are captured accurately, providing invaluable insights into operational dynamics.

    In addition to its robust analog capabilities, the PCI-6229 features 16 digital I/O lines, enabling seamless integration with digital control systems and actuators. Whether interfacing with PLCs, relays, or other digital devices, this module ensures reliable data exchange and control functionality.

    Operational in a wide temperature range from -40°C to +85°C, the PCI-6229 is designed for harsh industrial environments. Its rugged construction and durable materials guarantee reliable performance under extreme conditions, ensuring continuous operation without downtime.

    Featuring a PCIe interface, the PCI-6229 easily connects to modern computing platforms, including desktop computers and server systems. Its compatibility with popular data acquisition software tools allows for seamless setup and integration, streamlining the process of data collection and analysis.
