Operating Voltage:12V DC

Current Consumption:≤ 50mA

Resolution:1 μm

Communication Interface:RS-485

Max. Pulse Frequency:20 kHz

Temperature Range:-20°C to +85°C

Enclosure Rating:IP65

    The Koyo D4-PULS-1 Single Axis Pulse Module is engineered to deliver exceptional performance in demanding industrial environments. This compact yet powerful module is equipped with advanced features for precise control over single-axis applications. Its robust design ensures reliable operation across a wide range of temperatures and humidity levels, making it suitable for various industrial settings.

    With a high-resolution timing capability of 1μs, this module offers unparalleled accuracy for timing-sensitive operations. Users can customize pulse widths from a minimum of 1μs up to 20ms, providing flexibility for diverse automation needs. The open collector output type supports a broad input voltage range of 0V to 24V, ensuring compatibility with various control systems.

    The module is built to withstand harsh conditions, boasting an operating temperature range of -20°C to +85°C and a non-condensing humidity level of 5% to 95%. These environmental specifications guarantee continuous operation even in challenging industrial environments. Additionally, its compact size (70mm x 44mm x 22mm) and lightweight (approx. 50g) make it easy to integrate into space-constrained systems.

    In terms of connectivity, the Koyo D4-PULS-1 module utilizes standard industry protocols, facilitating seamless integration with existing control systems. It is designed with ease of use in mind, featuring straightforward installation and configuration procedures, which significantly reduce setup time and enhance productivity.

    For users seeking a high-performance, versatile, and reliable solution for single-axis control in industrial automation, the Koyo D4-PULS-1 Single Axis Pulse Module is an ideal choice. Its combination of precision, durability, and adaptability makes it a valuable asset in modern industrial setups.
