Module Type:Industrial Automation

Operating Voltage:24V DC

Current Consumption:≤100mA

Communication Interface:RS-485

Input Signals:10-bit ADC

Output Channels:2x Relay, 2x PWM

Operating Temperature Range:-20°C to +60°C

Protection Class:IP20

Dimension:100mm x 65mm x 35mm

Weight:0.1kg

    The JL Electronics 09137090112-A05 is engineered with robust materials and advanced circuitry to withstand harsh industrial environments. Its compact design ensures minimal space usage while providing maximum performance.

    Featuring an intuitive user interface, the module simplifies setup and operation, allowing technicians and engineers to quickly integrate it into their existing systems without requiring extensive training.

    With its fast response time and wide operating temperature range, this module is ideal for applications requiring precise control over temperature, pressure, and flow in various industrial sectors such as manufacturing, mining, and power generation.

    Equipped with a 12-bit A/D converter, it offers high accuracy in data acquisition, crucial for monitoring and controlling process variables in real-time. The RS485 communication interface supports easy data transfer, enhancing system interoperability.

    Durability is a key feature of the JL Electronics 09137090112-A05, backed by rigorous testing protocols. This ensures not only longevity but also consistent performance across different operational scenarios.
