HIMA F8627
1. Overview
Product Positioning: HIMA F8627 is a core module of HIMA’s safety control system (HIMAX/HIQuad), specifically designed for building highly reliable Safety Related Control Systems.
Core Features: Modules in this series are typically based on Intel Atom processors and support stackable modular design, enabling flexible combination of CPU, communication, and I/O within the same rack.
Application Scenarios: Widely used in safety-critical fields such as chemical, oil & gas, and power generation industries, aiming to meet strict safety integrity level requirements like SIL 2/3.
2. Parameters
|
Parameter
|
Typical Specification
|
Remarks
|
|---|---|---|
|
Processor
|
Intel Atom E3845 (x86-based)
|
64-bit processor, compatible with modern operating systems and safety software
|
|
Memory
|
4 GB DDR3L SDRAM
|
Supports large-capacity program and data storage
|
|
Storage
|
32 GB SSD
|
Supports fast reading/writing and redundant storage
|
|
Input Voltage
|
24 V DC
|
Complies with industrial standard power supply requirements
|
|
Communication Interfaces
|
Ethernet (Fast Ethernet/Modbus TCP/OPC), RS-485, CAN
|
Supports multiple industrial network protocols for remote monitoring and configuration
|
|
Operating Temperature
|
-20°C – +60°C (Standard); -40°C – +70°C (Some communication modules)
|
Designed for harsh industrial environments
|
|
Dimensions
|
175 mm x 100 mm x 25 mm (Communication module)
|
Modular standard size, easy for stacking
|
3. Product Features
- Modular Design: Adopts a stackable structure, supporting flexible I/O expansion (e.g., adding more than 20 I/O modules) to facilitate customization according to on-site requirements.
- Safety and Reliability: Complies with SIL 3 certification standards, featuring redundant architecture and fault-tolerant design to ensure safe shutdown even in case of hardware failures.
- Data Security: Communication modules support data encryption, identity authentication, and access control to ensure the security of network transmission.
- Easy Integration: Supports standard industrial protocols (Modbus TCP, Profibus, EtherNet/IP, OPC DA/A&E), enabling seamless connection with equipment from multiple manufacturers.
- Powerful Processing Capacity: Based on modern CPU, supporting complex safety logic operations and high-speed data processing.
4. Structure and Components
- CPU Module (F8627 CPU): Core control unit responsible for running safety control logic, usually with built-in redundant power supply and fault diagnosis functions.
- Communication Module (F8627 Ethernet/Communication): Provides Ethernet interfaces, supports multiple network protocols, and enables communication with upper-level systems or other PLCs.
- Digital Input Module (F8627X Digital Input): SIL 3-certified safety digital input module with 32 channels or more, supporting 2-5VDC input signals.
- Other I/O Modules: Such as analog input/output, pulse counter (HSO4), etc., forming a complete I/O expansion system.
5. Application Fields
- Process Industry: Safety Instrumented Systems (SIS) in oil, chemical, and natural gas processing plants.
- Power Plants: Safety-critical control systems in thermal power plants and nuclear power plants.
- Power Transmission and Distribution: Protection and control of power transmission and distribution systems.
- Water Treatment: Safety automation systems in large water plants.
————————————————————————————————-
