GE VMIVME-5567-000

Overview

GE VMIVME-5567-000 is a core component of the PACSystems RX7i series from GE Intelligent Platforms (now Emerson Automation). It is designed for industrial automation systems to enable data sharing and high-speed communication between PLCs. Based on Reflective Memory technology, it provides deterministic data transmission via a fiber optic network, ensuring the real-time performance and reliability of industrial control systems. This module operates independently of the CPU, enabling data exchange without CPU processing, making it suitable for high-demand industrial scenarios.

Parameters

Basic Parameters

Model: IC698CMX016 VMIVME-5567-000 Manufacturer: General Electric (GE) / Emerson Automation Product Type: Control Memory Exchange Module Compatibility: Supports the PACSystems RX7i platform and is compatible with various industrial control systems (such as Allen Bradley, Siemens, GE FANUC, Schneider, etc.).

Technical Specifications

Memory Capacity: 16MB with parity check function. Communication Interfaces: Fiber Optic Port: Supports a transmission rate of 2.12 Gbaud, with a maximum distance of 300 meters (multimode fiber). Data Packet Size: 4-64 bytes, maximum network transmission rate of 43-174 MB/s. Number of Nodes: Supports up to 256 nodes. Operating Voltage: +5VDC (provided by a power adapter). Power Consumption: 30 watts (standard single-slot module). Operating Temperature: -25°C to 70°C (some models support -40°C to 85°C). Physical Dimensions: Standard single-slot module (specific dimensions vary slightly by model, such as 115x75x35mm or 10.5×7.5×2.5cm). Weight: Approximately 0.4kg (some data incorrectly mark it as 150g; please refer to official data for accuracy).

Expansion Capability

Supports modular expansion, allowing flexible addition of peripheral devices. Compatible with 1762 MicroLogix expansion I/O modules.

Application Fields

Industrial Automation

Used for data sharing between PLCs to optimize control logic. Supports robot control systems, conveyor belt control, packaging machine control, etc.

Energy and Manufacturing

Widely used in power plant DCS monitoring systems, chemical plant liquid constant flow control systems. Suitable for discrete manufacturing fields such as automobile manufacturing, food processing, and textile machinery.

Special Industries

Oil and gas, water treatment, rail transportation, boiler heating, etc. Integrates with Mark VI gas turbine control systems to achieve efficient energy management.

Installation and Maintenance

Installation Steps

Insert the module into the designated slot (slot 3 or 4) of the RX7i CPU rack. Connect the fiber optic cable to the LC port, ensuring the distance does not exceed 300 meters. Configure via Proficy Machine Edition software.

Maintenance Recommendations

Regularly check the LED status indicators to confirm the system operation status. Use the Modbus protocol for remote diagnosis and troubleshooting. When replacing a damaged module, ensure the new module has the same version as the old one.

————————————————————————————————-
