GE THJK636F000

Product Overview

The GE THJK636F000 is a medium-power model belonging to the GE THJK series, featuring a modular design. It is mainly used for heating and drying applications in industrial workshops, warehouses, production lines, and industries such as plastics, textiles, and printing. Its core function is to convert electrical energy into thermal energy, generating a strong hot air flow to quickly raise ambient temperatures or achieve surface drying of products.

______________________________________________________________________________________________

Technical Specifications

Parameter	Specification
Rated Power	6.3 kW (6300W)
Power Supply Voltage	380V / 400V / 415V three-phase AC, 50/60Hz
Rated Current	Approx. 10.5 A (varies with specific voltage)
Power Supply Mode	Three-phase four-wire system
Overall Dimensions	Approx. 630 mm (L) × 360 mm (W) × 260 mm (H)
Weight	Approx. 30-35 kg
Air Volume	Approx. 0.8 – 1.2 m³/s (depends on fan speed)
Air Outlet Temperature	Maximum up to 450°C (under no-load condition); normal operating temperature set between 150°C – 250°C
Housing Material	High-temperature resistant steel plate (galvanized or painted for anti-corrosion treatment)
Protection Grade	IP44 (may vary slightly according to regional standards)

______________________________________________________________________________________________

Product Features

High Heating Efficiency

Equipped with high-quality resistance wire heating tubes, featuring high heat transfer efficiency and fast thermal response. The hot air circulation system is designed to make full use of heat and reduce energy waste.

Precise Temperature Control

Built with a high-precision electronic thermostat, ensuring minimal temperature fluctuation (±1-2°C). Supports PID adjustment algorithm, which stabilizes temperature rapidly even under varying load conditions.

Modular Structure

The main unit is compact in size, making it easy to install in narrow spaces. It adopts plug-and-play cable connectors for convenient component maintenance and replacement.

______________________________________________________________________________________________

Structure and Components

The GE THJK636F000 consists of the following typical components:

Electric Heating Assembly

Resistance wire tube (main heating element): Usually made of nickel-chromium alloy or tungsten alloy. Tube shell: A metal tube covering the resistance wire, acting as a heat transfer medium.

Fan Assembly

Centrifugal fan (or axial fan): Responsible for forcefully delivering heated air. Motor: Drives the fan operation, typically an AC single-phase or three-phase motor.

______________________________________________________________________________________________

Typical Applications

Application Scenario	Specific Function
Industrial Workshop Heating	Maintains workshop temperature in winter and provides a comfortable working environment.
Plastic Product Drying	Post-processing drying of plastic pipes, profiles, and films.
Textile Printing and Dyeing	Heating and drying of cloth or dyed textiles.
Food Packaging	Hot air setting or drying for food packaging machines.
Laboratory Heating	Air heating or equipment drying on laboratory benches.
Chemical Processing	Certain chemical production processes requiring hot air circulation.

————————————————————————————————-
