GE TED136035WL
GE TED136035WL is a 35A HACR (High Ampere Circuit Breaker) green label circuit breaker produced by General Electric (GE), belonging to the TED series. It is a special-purpose circuit breaker designed for high-current applications, mainly used for main protection and branch protection in power distribution systems.
______________________________________________________________________________________________
1. Core Overview
Model Interpretation: TED136035WL
- TED: Series code (High Ampere Circuit Breaker)
- 136: Rated current of 35A (including two specifications: 30A and 35A)
- 03: Rated voltage of 600V
- 5: 3-pole
- WL: Green Label
Main Function: It is used to detect overload and short-circuit faults in the circuit and automatically disconnect the circuit to protect electrical equipment and lines.
______________________________________________________________________________________________
2. Key Parameters
|
Parameter
|
Specification
|
|---|---|
|
Rated Current (In)
|
35A
|
|
Rated Voltage (Ue)
|
600V
|
|
Pole Number
|
3-pole
|
|
Pole Spacing
|
32mm
|
|
Mounting Method
|
DIN Rail Mounting
|
|
Breaking Capacity
|
>30kA
|
|
Housing Color
|
Green
|
|
Protection Level
|
IP20
|
|
Marking
|
HACR (High Ampere Circuit Breaker, dedicated for high current)
|
______________________________________________________________________________________________
3. Product Features and Advantages
- Dedicated for High Current: Belonging to the HACR series, it is specially designed for high-current applications from 35A to 90A, capable of withstanding large starting currents and overload currents.
- Optimized Pole Spacing: The pole spacing is 32mm, wider than conventional circuit breakers, suitable for high-current power distribution systems, reducing electrical clearance and improving safety.
- Green Label Certification: As a green label product, it meets GE’s high energy efficiency and environmental protection standards, and is usually used in projects requiring energy-saving certification.
- Durable: Made of high-strength materials, the housing is wear-resistant, corrosion-resistant, and has a long service life.
- Reliable Protection Performance: Equipped with high-sensitivity thermal-magnetic protection components, it can quickly cut off fault currents.
______________________________________________________________________________________________
4. Structure and Composition
- Housing: Metal housing (green), providing physical protection and fixing the position of the circuit breaker on the DIN rail.
- Contact: Responsible for current transmission in the on state and cutting off the circuit when disconnected.
- Thermal Magnetic Element: The core protection device, responsible for detecting overload (thermal) and short-circuit (magnetic) faults and triggering disconnection.
- Trip Unit: Responsible for driving the contacts to quickly break in case of faults.
- Indicator: Usually equipped with a handle or indicator light to show the on/off state of the circuit breaker.
______________________________________________________________________________________________
5. Typical Application Fields
- Industrial Power Distribution Systems: Used for main circuit protection in factory workshops, especially in occasions with large motor starting currents.
- Building Electrical Systems: Used as a branch protection component in electrical distribution boxes of large buildings.
- Energy Stations: Used for protection of high-current equipment such as generator sets and transformers.
- Commercial Facilities: Such as power distribution systems of large-scale facilities like shopping malls and hospitals.
————————————————————————————————-
