GE TED134110WL
GE TED134110WL is a molded case thermal-magnetic circuit breaker of the TCAL series under General Electric (GE), specifically designed for electrical systems in industrial and commercial buildings. Due to its compact “White Box” design and efficient thermal-magnetic tripping mechanism, this product is widely used in medium-voltage power distribution and control systems.
______________________________________________________________________________________________
1. Key Technical Parameters and Electrical Characteristics
|
Parameter
|
Specification
|
Description
|
|---|---|---|
|
Rated Current
|
110A
|
Rated operating current, meeting the needs of small and medium-sized industrial loads.
|
|
Rated Voltage
|
480V AC
|
Suitable for three-phase four-wire industrial power supply systems.
|
|
Poles
|
3 Poles
|
Typical three-phase circuit breaker design.
|
|
Tripping Characteristic
|
Thermal-Magnetic
|
Combines thermal tripping (overload protection) and magnetic tripping (short-circuit protection) to provide double safety guarantee.
|
|
Frequency
|
50/60Hz
|
Compatible with major global industrial power frequencies.
|
|
Installation Method
|
Molded Case (MCCB)
|
Compact design, suitable for installation in distribution cabinets.
|
|
Overall Dimension
|
WL Series (White Box)
|
Adopts white shell design, relatively compact in size, easy to arrange in narrow spaces.
|
|
Frame Type
|
TCAL
|
Standard GE power distribution system frame, easy to integrate with other GE power distribution components.
|
______________________________________________________________________________________________
2. Product Features and Advantages
Compact and Efficient Design
WL (White Box) Series: This series adopts a white shell and is relatively small in size. Compared with traditional “red box” or “black box” circuit breakers, the WL series occupies less space in the distribution cabinet, making it suitable for industrial power distribution environments with limited space.
Reliable Thermal-Magnetic Tripping Technology
It combines thermal tripping (overload protection) and magnetic tripping (short-circuit protection) functions. When the current exceeds the set value, it can cut off the circuit quickly and reliably to protect downstream equipment from damage.
Strong Compatibility
As a member of the TCAL series, this product can be easily integrated with other GE electrical components (such as switches, sockets, and control panels) to build a unified and reliable power distribution system.
______________________________________________________________________________________________
3. Structure and Composition
- Housing: White insulating shell, providing mechanical support and electrical insulation.
- Trip Unit: Contains thermal elements (bimetallic strips) and magnetic trip coils, which are the core protection components.
- Circuit Breaker Contacts: Used to cut off and connect the circuit.
- Auxiliary Contacts: Provide additional signal output or circuit interlocking functions.
- Terminal Block: Used to connect the power supply and load wires of the power distribution system.
______________________________________________________________________________________________
4. Typical Application Fields
- Industrial Power Distribution: Main power protection for places such as machine tools, production lines, and industrial control cabinets.
- Commercial Buildings: Floor power distribution of office buildings and shopping malls, or branch circuit protection of large electrical equipment.
- Pump and Fan Control: Suitable for the start-stop and protection control of large pumps, fans and other motors.
______________________________________________________________________________________________
5. Installation and Maintenance Recommendations
- Installation Requirements: It is recommended that professional electricians install according to the power distribution drawings to ensure firm wiring and compliance with electrical specifications.
- Regular Inspection: Regularly check the wiring of the circuit breaker and the wear degree of the contacts to ensure that its tripping function is normal.
————————————————————————————————-
