GE TEB122100
GE TEB122100 is a high-performance Permanent Magnet Synchronous DC (PMDC) motor launched by General Electric (GE). It is widely used in industrial automation, robotics, and precision control fields. Characterized by high power density, low noise, easy maintenance, and precise control, it is suitable for scenarios that require stable output and high energy efficiency.
______________________________________________________________________________________________
1. Key Specifications
|
Parameter Category
|
Specific Value/Range
|
Description
|
|---|---|---|
|
Rated Power
|
0.25kW – 1.0kW
|
Suitable for low-power loads
|
|
Rated Voltage
|
24V / 48V / 110V / 220V
|
Multiple voltage options available
|
|
Rated Speed
|
1500rpm / 3000rpm
|
Capable of high-speed operation
|
|
Rated Current
|
1.5A – 6.5A
|
Depends on the voltage model
|
|
Protection Class
|
IP54 / IP55
|
Dustproof and waterproof, suitable for industrial environments
|
|
Braking Function
|
Including braking resistor
|
Provides fast braking capability
|
|
Structural Material
|
Metal shell
|
Sturdy and durable structure
|
______________________________________________________________________________________________
2. Key Features
- Permanent Magnet Synchronous Technology: Uses permanent magnets, featuring zero slip, fast response, and high precision.
- High Power Density: The power density can reach 1.5-2.0 kW/L, saving installation space.
- Low Noise: The noise level is below 70dB(A), suitable for noise-sensitive environments.
- Easy Maintenance: Adopts an open structure design, ensuring good heat dissipation and convenient maintenance.
- Optional Braking Resistor: Provides fast braking function to improve operational safety.
______________________________________________________________________________________________
3. Structure and Composition
- Motor Body: A permanent magnet synchronous motor, mainly composed of stator, rotor, and bearings.
- Braking Resistor: Optional, installed on the motor side cover or base to enhance braking performance.
- Motor Junction Box: Used to connect power and control lines, usually equipped with a protective cover.
- Base/Bracket: Used for fixed installation; some models may adopt flange mounting.
______________________________________________________________________________________________
4. Application Areas
- Robotics: Joint drive, end effector.
- Industrial Automation: Conveyor belts, valve actuators.
- Machine Tools: Spindle drive of CNC machine tools.
- Precision Instruments: Test equipment, laboratory instruments.
______________________________________________________________________________________________
5. Installation & Maintenance
- Installation Method: Usually adopts flange mounting or base fixation; ensure the motor axis is concentric with the load.
- Electrical Wiring: Wire according to the rated voltage (such as 24V/48V) and ensure correct phase sequence.
- Lubrication and Maintenance: Check the bearing lubrication status regularly to prevent wear.
- Braking Resistor Maintenance: If a braking resistor is used, regularly check the resistor power to avoid overheating.
————————————————————————————————-
