GE SRPE30A15

Parameters

• Rated Current: 30A
• Applicable Series: SED, SEH, SEL, SEP
• Type: Plug-in circuit breaker connector
• Brand: GE
• Model: SRPE30A15
• Installation Method: Fixed by bolts
• Protection Class: IP67 (for some models)
• Connector Type: M12-A
• Cable Connector: M12-A right-angle female, 5-pin
• Weight: Net weight 0.64kg, gross weight 0.88kg (including 5-meter cable)
• Packaging Size: 200 x 145 x 160 mm

Product Features

• High Reliability: Uses GE high-quality materials and manufacturing processes to ensure long-term stable operation.
• Easy Installation and Maintenance: Compact design, simple installation, and convenient maintenance.
• Strong Compatibility: Suitable for multiple GE circuit breaker series, with good versatility.
• Safety Protection: IP67 protection class effectively prevents dust and water from entering.
• Durability: Made of corrosion-resistant materials, suitable for various harsh environments.

Structure and Composition

• Main Structure: Consists of a housing, internal connectors, and fixing bolts.
• Connecting Components: Include M12-A connectors, cable entries, and sealing rings.
• Fixing Method: Fixed by M5 and M6 bolts, with center distances of 46mm and centered respectively.
• Desiccant: Contains 2 bags of silica gel desiccant inside to keep the interior dry.
• Ventilator: Equipped with vents to ensure good heat dissipation.

Application Fields

• Industrial Automation: Used for circuit protection and connection in industrial control systems.
• Power Systems: Suitable for circuit breaker connection in power facilities such as power plants and substations.
• Building Electrical: Used in power distribution systems within buildings.
• Manufacturing Industry: Widely applied in machinery manufacturing, automobile manufacturing, and other industries.
• Energy Industry: Used for electrical connection in new energy power generation equipment such as wind energy and solar energy.

Installation and Maintenance

Installation Steps:

1. Ensure the installation location meets the requirements and select a suitable installation site.
2. Fix using M5 and M6 bolts to ensure a firm connection.
3. When installing the cable, pay attention to the direction and type of the connector.
4. Check if the sealing ring is intact to ensure tightness.
5. After installation, conduct a preliminary test to ensure everything is in order.

Maintenance Recommendations:

• Regularly check the tightness of the connectors to prevent loosening.
• Inspect the condition of the desiccant and ventilator, and replace them if necessary.
• Keep the equipment clean to avoid dust and moisture intrusion.
• It is recommended to replace the desiccant and ventilator during equipment calibration.

————————————————————————————————-
