Brand:GE

Model:SR750-P5-G5-S5-HI-A20-R-T

Series:Multilin Relay

Origin:U.S.

Order Number:SR750-P5-G5-S5-HI-A20-R-T

Custom Processing:Yes

Certified Product:SR750-P5-G5-S5-HI-A20-R-T

Operating Voltage:220V

Output Frequency:50 kHz

Analog Outputs:8 x 4-20mA

Communication Protocol:Modbus RTU or DNP 3.0

Insulation Voltage:300V

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

    The GE SR750-P5-G5-S5-HI-A20-R-T Multilin Relay offers an enhanced display with integrated Ethernet connectivity, making it ideal for modern industrial control applications. With its robust design and high-performance specifications, this relay ensures reliable operation in demanding environments.

    Designed for distribution feeder control and protection, this relay supports eight 4-20mA analog outputs, providing versatile monitoring capabilities. The red breaker closed LED indicator ensures easy visual monitoring of system status.

    This model operates within a frequency range of 25 to 60 Hz nominal, ensuring compatibility with various electrical systems. Its insulation voltage rating of 300V guarantees safe and efficient operation under different conditions.

    With a wide overvoltage pickup level ranging from 0 to 1.25 × VT in steps of 0.01, this relay offers precise and reliable overvoltage detection. Additionally, it captures waveform data from four current channels, three voltage channels, and 14 logic input states.

    The GE SR750-P5-G5-S5-HI-A20-R-T is compatible with Modbus RTU or DNP 3.0 communication protocols, enabling seamless integration with existing control systems. Its compact design allows for easy installation on standard 19-inch panels, either alone or alongside other 750 units.
