GE QPK3D200L2P
Product Overview
GE QPK3D200L2P is a high-performance Industrial Human-Machine Interface (HMI) under the General Electric (GE) QuickPanel+ Series, specifically designed for industrial automation control systems. It is suitable for application scenarios such as process control, machinery manufacturing, and energy management. This HMI integrates functions including touchscreen display, data acquisition, and logic control, supporting seamless communication with GE PLCs (e.g., RX3i, VersaMax), third-party controllers (e.g., Siemens, Allen-Bradley), and SCADA systems. It provides an intuitive operation interface and real-time monitoring capabilities.
The core values of QPK3D200L2P are as follows:
- Multifunctional Integration: Combines HMI and PLC functions to reduce the complexity of hardware configuration.
- High-Resolution Display: Offers a clear graphical operation interface and supports multi-language display.
- Flexible Communication: Supports a variety of industrial protocols (e.g., Modbus TCP/IP, Ethernet/IP, Profibus).
Product Specifications
- Product Model: QPK3D200L2P
- Manufacturer: General Electric (GE)
- Product Type: Industrial Human-Machine Interface (HMI)
- Screen Size: 12.1-inch TFT LCD
- Resolution: 800×600 (SVGA)
- Touchscreen Type: Resistive/Capacitive (depending on version)
- Processor: High-performance ARM or x86 architecture
- Memory: 512MB RAM / 2GB Flash (expandable)
- Communication Interfaces: 2× Ethernet (10/100Mbps), 1× RS-232/485, USB
- Supported Protocols: Modbus TCP/IP, Ethernet/IP, Profibus, OPC UA
- Operating System: Windows CE / Linux (depending on version)
- Operating Temperature Range: 0°C to +50°C (32°F to 122°F)
- Protection Class: IP65 (front panel) / IP20 (rear panel)
- Installation Method: Panel-mounted embedded installation
- Power Supply Voltage: 24V DC (±10%)
- Power Consumption: ≤25W
Structure and Composition
QPK3D200L2P adopts an industrial-grade integrated design, with main components including:
- Display Module: High-brightness TFT LCD that supports wide-temperature operation and adapts to strong light environments.
- Touchscreen Layer: Resistive or capacitive touch panel, supporting glove operation (depending on version).
- Core Processing Unit: High-performance processor running a real-time operating system (e.g., Windows CE) to execute HMI logic and communication tasks.
- Communication Interface Board: Integrates dual Ethernet, serial ports, and USB, supporting multiple industrial protocols.
- Power Management Module: Features wide voltage input (24V DC) and built-in overvoltage/reverse connection protection.
- Enclosure: The front panel has IP65 protection (dustproof and waterproof), and the aluminum alloy frame enhances heat dissipation.
Application Fields
QPK3D200L2P is suitable for the following scenarios:
- Energy Management: Control interface for gas turbines/steam turbines, displaying real-time parameters such as temperature, pressure, and speed.
- Manufacturing Industry: Monitoring of production line equipment (e.g., injection molding machines, packaging machines).
- Water Treatment: Visual operation of data such as pump station flow rate and pH value.
- Transportation Infrastructure: Control panel for tunnel ventilation systems.
Typical Application Case
In chemical plants, QPK3D200L2P serves as a central operation station. It connects to the GE RX3i PLC via Modbus TCP to monitor the temperature and pressure of reactors in real time and record historical data.
————————————————————————————————-
