GE L28403P02
1. Overview
GE L28403P02 is a low-voltage electrical control switchgear produced by GE Electrical. This product is usually used for power distribution, control and protection in industrial sites. As a standardized electrical control device, it emphasizes modularity and flexibility in design, and can adapt to the needs of different industrial environments.
______________________________________________________________________________________________________
2. Parameters
|
Parameter
|
Specification/Range
|
|---|---|
|
Rated Voltage
|
380V/400V/415V
|
|
Rated Current
|
0.25A – 4000A
|
|
Rated Power
|
Up to 100kW
|
|
Breaking Capacity
|
25kA (Standard)
|
|
Protection Level
|
IP20 (Internal Installation) / IP54 (Enclosure)
|
|
Installation Method
|
Floor-mounted, Wall-mounted (Optional)
|
|
Ambient Temperature
|
-25°C – +55°C
|
______________________________________________________________________________________________________
3. Product Features
- Modular Design: Adopts a modular structure, which is convenient for on-site installation and future expansion.
- High Reliability: Uses high-quality low-voltage components internally, with good overload and short-circuit protection capabilities.
- Excellent Protection Performance: Equipped with dust-proof and water-proof functions, suitable for industrial site use.
- Easy Maintenance: Adopts screw crimping technology, with reliable connection and convenient disassembly and assembly.
______________________________________________________________________________________________________
4. Structure and Composition
- Main Circuit Components: Circuit breakers, fuses, isolating switches.
- Control Circuit Components: Contactors, thermal relays, indicator lights, buttons.
- Auxiliary Components: Relays, speed relays, rectifier bridges, etc.
- Terminals: Used for wiring of internal circuits, usually adopting screw crimping technology.
______________________________________________________________________________________________________
5. Application Fields
- Industrial Automation: As an on-site control cabinet, it cooperates with PLC or DCS for automatic control.
- Power Distribution: As low-voltage distribution equipment in power transformation and distribution stations.
- Building Facilities: Used in power distribution systems of large commercial buildings or industrial parks.
- Mining and Petrochemical: Suitable for high-reliability demand scenarios such as mines and petrochemical plants.
______________________________________________________________________________________________________
6. Installation and Maintenance
Installation Steps
- On-site Survey: Determine the protection level requirements (IP20 or IP54) of the installation location.
- Positioning and Installation: Choose wall-mounted or floor-mounted installation according to on-site conditions.
- Cable Wiring: Connect the power lines and control lines according to the wiring diagram to ensure firm crimping.
Maintenance Points
- Regular Inspection: Regularly check the tightness of cable terminals and screws to prevent poor contact caused by vibration.
- Cleaning and Protection: Keep the cabinet surface clean to prevent dust from entering internal components.
- Function Test: Regularly conduct trip and closing tests to ensure that protective components such as circuit breakers function normally.
————————————————————————————————-
