1. Product Overview

2. Core Specifications

• Operating Voltage: 24 VDC
• Operating Temperature Range: -40°C to +85°C
• Digital Output Module Specifications:
  • Output Points: 16-point digital output
  • Output Current: 2 A (standard configuration)
  • Output Voltage Range: 0-10 VDC
• Dimensions and Weight:
  • Dimensions: Approx. 100mm x 50mm x 30mm
  • Weight: Approx. 200-300 grams

_______________________________________________________________________________________________________

3. Product Features

• High Reliability: Designed to withstand harsh industrial operating conditions, the module features exceptional resistance to electromagnetic interference (EMI) and excellent tolerance to high temperatures and humidity, ensuring consistent performance in demanding industrial settings.
• User-Friendly Design: Adopts a compact modular structure and supports DIN rail mounting, enabling quick on-site assembly, installation, and replacement without complex tools, reducing downtime for maintenance and upgrades.
• Flexible Connectivity: Equipped with multiple connection options including screw terminals and plug connectors for versatile wiring. Select models support communication protocols such as Modbus RTU, facilitating seamless integration with industrial control networks.
• Built-In Diagnostic Capabilities: Premium variants come with self-test and fault diagnosis functions, allowing maintenance personnel to quickly identify and resolve system faults, minimizing troubleshooting time and improving overall system uptime.

_______________________________________________________________________________________________________

4. Structure and Components

• I/O Terminals: Used for connecting sensors, actuators, and other peripheral control equipment to transmit and receive control signals.
• Power Supply Module: Converts external input power into stable operating voltage required for the module’s internal circuits, ensuring reliable power delivery.
• Signal Conditioning Circuitry: Processes and amplifies weak sensor signals for sensor-integrated models, enhancing signal accuracy and transmission stability.
• Communication Interface: Select models are equipped with Ethernet or RS485 interfaces, enabling data transmission and communication with host computers and upper-level control systems.
• Status Indicators: Visual LED indicators to display real-time module operating status, including active operation status and fault alarm prompts for intuitive monitoring.

_______________________________________________________________________________________________________

5. Application Areas

• Energy Industry: Turbine control systems for oil and gas extraction, natural gas processing, and power generation plants.
• Chemical and Manufacturing: Industrial process control, automated production line management, and chemical plant equipment control.
• Power and Metallurgy: Power grid equipment monitoring, metal smelting process automation, and heavy industrial control.
• Other Industries: Automation control applications in papermaking, food and beverage production, textile manufacturing, rubber processing, and more.
