1. Overview

2. Technical Parameters

• Number of Channels: 2 parallel channels per unit
• A/D Resolution: 12-bit
• Sampling Rate: Up to 5MHz, supporting multiple modes such as 2MHz, 1MHz, 500kHz, and 500Hz
• Storage Depth: 512k samples per channel
• Trigger Modes: Manual trigger, internal trigger, external trigger
• Working Modes: Online / Offline (Black Box)
• Signal Input: V/Q or V/I CP
• Communication Interface: RJ45 Ethernet interface
• Sensor Excitation: Bridge voltage 2V-10V/5-20mA, constant current 4mA/24V
• Power Supply: Built-in lithium battery (for some models)
• Cascading Capacity: 1-16 units (32 channels)
• Dimensions: Approximately 1160mm x 110mm x 60mm
• Net Weight: Approximately 2kg (including battery)

3. Product Features

• High Flexibility: Modular design, supporting flexible configuration of multiple I/O modules and communication interfaces
• Easy Programming: Compatible with multiple programming languages, adapting to different users’ development habits
• High Reliability: Wide voltage input range, adapting to a wide range of temperature and humidity environments to ensure stable on-site operation
• Easy Integration: Provides multiple communication interfaces (such as Ethernet) for easy data exchange and network connection with other devices or systems
• Precise Sampling: Sampling rate up to 5MHz, suitable for high-frequency signal capture and analysis

4. Structure & Composition

Core Components

Indicators & Connections

• Red LED indicates “LINK ABOVE 50V”
• Multiple jumper pins for signal connection (such as PL, PL1, PL2)
• UGB and UEB metal components are provided at the bottom for power supply and ground connection

Terminals & Interfaces

5. Application Fields

• Power System: Used for condition monitoring and automatic control of generator sets
• Chemical & Metallurgy: Monitoring key parameters and safety valves during the reaction process
• Pharmaceutical & Food: Data acquisition and quality control to ensure the production process complies with standards
• Others: Suitable for any industrial automation environment that requires high-frequency sampling, data storage, and real-time analysis

6. Installation & Maintenance

Installation Guide

• Power Check: Before installation, please check whether the power supply voltage is within the nominal range of the module, and confirm whether the internal lithium battery needs to be replaced (if applicable).
• Jumper Connection: According to the system design drawing, connect the jumper pins (such as PL, PL1) to the corresponding I/O terminal board or sensor.
• Network Access: Use an RJ45 cable to connect the Ethernet interface to realize remote monitoring or communication with PLC.
• Cascading Installation: If channel expansion is needed, multiple modules can be connected in series through the cascading interface, supporting up to 16 modules in cascading.
