1. Core Parameters

• Thrust Capacity: Usually between 1000N and 5000N (specific value depends on the specific configuration).
• Stroke Range: The minimum stroke is about 50mm, and the maximum stroke can reach 300mm or longer.
• Accuracy: Positioning accuracy can reach 0.01mm level.
• Speed: Supports high-speed movement, with a peak speed usually up to 2m/s or higher.
• Feedback Device: Built-in multi-turn absolute encoder to provide real-time position feedback.

______________________________________________________________________________________________

2. Product Features

• High-Precision Closed-Loop Control: Achieves extremely high positioning accuracy and repeat positioning accuracy through servo motors and encoders.
• Low Noise and Low Pollution: No risk of hydraulic oil leakage, low operating noise, suitable for clean rooms and places with high environmental protection requirements.
• High Rigidity and Impact Resistance: Compact structure, strong rigidity, strong impact resistance and long service life.
• Easy Maintenance: Simple structure, no wearing parts, low maintenance cost, usually only regular greasing is required.

______________________________________________________________________________________________

3. Structure and Composition

• Electric Cylinder Body: Aluminum alloy or steel material, with ball screw inside.
• Servo Motor: Drive motor, responsible for providing power.
• Reduction Device: Planetary reducer or worm gear reducer, which reduces speed and amplifies torque.
• Lead Screw and Nut: Convert rotary motion into linear motion.
• Position Feedback Device: Multi-turn absolute encoder for accurately feeding back position information.

______________________________________________________________________________________________

4. Main Application Fields

• Industrial Automation: Robotic arms, CNC machine tools, packaging machinery.
• Paper Making and Chemical Industry: Used for web tension control and roller movement.
• Automobile Manufacturing: Assembly line automation, punch press control.
• Electronic Manufacturing: Precision assembly, placement machines.

______________________________________________________________________________________________

5. Installation and Maintenance

Installation Methods

• Front Flange/Rear Flange: Installed on the equipment frame through flanges.
• Side Flange: Suitable for lateral push rod installation.
• Tail Hinge: Suitable for occasions with limited space.

Maintenance Points

• Lubrication: Regularly check and supplement grease to prevent wear of the ball screw.
• Seal Inspection: Ensure the sealing ring is intact to prevent external contaminants from entering.
• Connection Inspection: Check whether the connection between the motor and the controller is firm to prevent signal loss.
