GE IC754CSI2CTD
Product Overview
GE IC754CSL12CTD is a high-performance industrial touchscreen HMI (Human-Machine Interface) from GE’s QuickPanel+ series. It features a 12.1-inch TFT color display with a resolution of 800×600, specifically designed for industrial automation and process control. This HMI supports Proficy Machine Edition and CIMPLICITY HMI development software, providing an intuitive operation interface suitable for PLC monitoring, data acquisition, and equipment diagnosis.
IC754CSL12CTD has a front panel with IP65 protection rating, which can resist dust and water splashes, making it suitable for harsh environments such as food processing, pharmaceuticals, and water treatment. Its rich communication interfaces (including serial ports, Ethernet, and USB) support seamless integration with GE Fanuc PLCs (such as RX3i and 90-30 series) and other third-party devices.
Product Parameters
- Product Model: IC754CSL12CTD
- Manufacturer: GE Intelligent Platforms (now Emerson)
- Product Type: Industrial Touchscreen HMI
- Screen Size: 12.1-inch TFT
- Resolution: 800×600 (SVGA)
- Touch Technology: Resistive (supports glove operation)
- Processor: 500MHz RISC
- Memory: 128MB RAM / 256MB Flash
- Communication Interfaces: 1×RS-232/485, 1×10/100M Ethernet, 2×USB 2.0
- Protection Rating: IP65 (front panel) / IP20 (rear panel)
- Operating Temperature: 0°C ~ +50°C
- Power Supply Voltage: 24V DC (±10%)
- Compatible Protocols: Modbus RTU/TCP, SNP, SRTP
- Certification Standards: CE, UL, cUL, FCC Class A
Structure and Composition
IC754CSL12CTD consists of the following core components:
Display and Touch Layer:
- High-brightness LCD screen (250cd/m²), supporting wide-temperature operation (optional -20°C~+60°C).
- Resistive touchscreen, responsive to gloved or stylus operations.
Processing and Communication Layer:
- 500MHz RISC processor running VxWorks real-time system.
- Dual USB interfaces supporting data export/external keyboards.
Installation and Protection Layer:
- Front panel with stainless steel bezel + polycarbonate panel, resistant to chemical corrosion.
- Supports panel mounting or VESA wall mounting (standard mounting kit included).
Main Features and Advantages
High Visibility Interface:
- 12.1-inch large screen + 65,536-color display, supporting multi-window simultaneous operation.
- Sunlight-readable (optional high-brightness version up to 1000cd/m²).
Strong Industrial Adaptability:
- IP65 protection, resistant to high-pressure water flushing (food/pharmaceutical industries).
- Passed 5G vibration test (IEC 60068-2-6).
Flexible Communication Integration:
- Natively supports GE Fanuc SNP protocol, seamlessly connecting with RX3i/90-30 PLCs.
- Optional Profinet/DeviceNet expansion modules (such as IC754VSI12CTD).
Efficient Development Tools:
- Use Proficy View Machine Edition for quick interface design.
- Supports CIMPLICITY HMI project migration.
Application Fields
- Food and Beverage: Monitoring of filling machines and packaging lines (compatible with FDA standards).
- Water Treatment: Pump station SCADA systems (cooperating with VersaMax PLC).
- Pharmaceuticals: Clean room equipment control (GMP compliant).
- Automotive Manufacturing: Welding robot status display (communicating with FANUC robot controllers).
————————————————————————————————-
