GE IC697VDD125

The GE IC697VDD125 is a dedicated digital output module for the General Electric (GE) Series 90-70 PLC system, belonging to the high-performance I/O components of the VersaMax™ series. This module provides 32 channels of isolated digital outputs and adopts Solid State Relay (SSR) technology, supporting high-speed switch control (≤1ms response time). It is suitable for critical applications in industrial automation such as motor control, valve driving, and alarm triggering.

Product Parameters

• Product Model: IC697VDD125
• Manufacturer: GE Fanuc
• Product Type: Digital output module
• Output Channels: 32 channels (solid state relay output)
• Output Type:
  • DC: 0.5A @ 120V DC
  • AC: 0.5A @ 120V AC
• Response Time: ≤1ms (ON/OFF switching)
• Isolation Voltage: 1500V AC (between channels / channel to ground)
• Leakage Current: <1mA @ 120V AC
• Backplane Communication: 90-70 VME bus
• Operating Temperature: -40°C ~ +70°C
• Protection Level: IP20 (must be installed in a control cabinet)
• Power Consumption: 6W (at full load)
• Compatible System: GE Series 90-70 PLC
• MTBF: 250,000 hours (IEC 61709)

Structure and Composition

Output Drive Layer:

• 32 channels of MOSFET solid state relays with no mechanical contacts, boasting a service life of up to 5 million operations.
• Each group consists of 8 channels (4 groups in total), with independent optocoupler isolated power supplies.

Protection Circuit Layer:

• Integrated TVS diodes (600W) and self-recovering fuses to protect against surges and short circuits.
• Built-in heat-dissipating aluminum substrate to ensure stable operation in high-temperature environments

————————————————————————————————-
