GE IC695PBM300
Overview
The GE IC695PBM300 is a PROFIBUS DP master module designed to enable communication with PROFIBUS-DP networks in PACSystems RX3i controllers. It supports communication with up to 125 PROFIBUS-DP slaves, with each slave capable of transmitting 244 bytes of input and 244 bytes of output data, resulting in a total data capacity of 3584 bytes for input and 3584 bytes for output. The module supports multiple data rates, ranging from 9.6 kBit/s to 12 MBit/s, making it suitable for high-speed data transmission.
Parameters
- Interface Type: RS-485 (PROFIBUS DP interface)
- Protocol Support: PROFIBUS DP
- Data Rates: Supports various standard data rates, including 9.6 kBit/s, 19.2 kBit/s, 93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s, 3 MBit/s, 6 MBit/s, and 12 MBit/s
- Number of Slaves: Up to 125 PROFIBUS-DP slaves
- Physical Characteristics: DIN rail mounting, industrial-grade design
- Backplane Current Consumption: 440 mA (3.3 V DC)
- Temperature Ranges: Operating temperature 0°C to 60°C; storage temperature -40°C to 85°C
Product Features
- High-Speed Data Transmission: Supports multiple data rates to ensure real-time response.
- High Reliability: Designed for industrial environments, offering high reliability and durability.
- Flexible Configuration: Can be flexibly configured via software to meet different application requirements.
- Diagnostic Functions: Provides status information such as slave status bit arrays, network diagnostic counters, DP master diagnostic counters, firmware module revisions, and slave diagnostic addresses.
- Indicator Lights: Features PROFIBUS OK, network, and MOD status indicators for monitoring device operation.
Structure and Composition
- Module Type: PROFIBUS DP master module, installed on the RX3i backplane.
- Connection Method: Connected to the PROFIBUS bus cable via a 9-pin Sub-D connector.
- Installation Method: DIN rail mounting, supporting universal backplane and PCI connections.
- Firmware Requirements: Requires RX3i CPU firmware version 2.9 or higher.
Application Fields
- Industrial Automation: Used in industrial automation systems to enable data transmission and communication between devices.
- Process Control: Applied in process control systems to manage process variables.
- Distributed Control Systems: Utilized in distributed control systems to connect multiple controllers.
- Specific Industries: Chemical, power, automotive manufacturing, aerospace, electrical, and other sectors.
Installation and Maintenance
- Installation Requirements: The module must be installed on the RX3i universal backplane, and the RX3i CPU firmware version must be 2.9 or higher.
- Configuration Requirements: Requires Machine Edition SP5 Logic Developer PLC software version 0.2 or higher.
————————————————————————————————-
