1. Overview

2. Key Parameters

• Voltage Rating: 100VDC (Direct Current Voltage)
• Current Specification: 2A (Typical Value)
• Power Dissipation: 2W
• Structure Type: NSFS (Non-Standard Form Factor)
• Operating Temperature Range: -30℃ – 85℃ (Suitable for Harsh Environments)
• Overall Dimensions: Miniaturized relay design, suitable for panel mounting.

______________________________________________________________________________________________

3. Product Features

• High Reliability: As a world-renowned brand, GE’s relays perform excellently in terms of service life and performance stability, suitable for high-intensity working environments.
• Compact Design: Adopting Non-Standard Form Factor (NSFS), it is small in size and suitable for installation on control cabinets or panels with limited space.
• Low Power Consumption: The operating power is only 2W, with low energy consumption and little heat generation.
• Wide Compatibility: This model is usually used with other models of GE HEA61 series (such as HEA61A235-X2), featuring good compatibility.

______________________________________________________________________________________________

4. Structure and Composition

• Coil Assembly: Responsible for generating magnetic field after power-on to realize switching action.
• Contact System: Including Normally Open (NO) contacts and Normally Closed (NC) contacts, used to control the on-off of the circuit.
• Housing: Adopting NSFS structure to provide physical protection and electrical insulation.
• Terminals: Used to connect power lines and load lines, usually adopting screw-type or snap-on connection.

______________________________________________________________________________________________

5. Application Fields

• Motor Control Systems: Used for starting, stopping and protecting motor operation.
• Industrial Instruments: Used as a protection relay to monitor circuit status.
• Automation Equipment: Used for robot control panels and automated production lines.
• Energy Management: Used for shunting and overload protection in power distribution cabinets.

______________________________________________________________________________________________

6. Installation and Maintenance Recommendations

• Installation Direction: Usually marked with “NO/NC” indication direction, ensuring that it is consistent with the circuit diagram during installation.
• Wiring: Ensure that the wiring terminals are fastened to prevent poor contact caused by vibration.
• Operating Environment: Try to avoid humid and highly corrosive environments and keep ventilation.
• Maintenance: Regularly check the contact status and coil resistance of the relay to prevent poor contact caused by aging.
