1. Overview

2. Specifications

• Model: GE FBV36TE015R2
• Pole Number: 3 Pole (3P)
• Rated Current: 15A
• Rated Voltage: 600V
• Rated Breaking Capacity: 35kA (common version, 100kA specification mentioned in some documents)
• Wiring Method: R2 (Load Lugs and Panel Connections) – including load terminals and panel connections

3. Product Features

• High Reliability: Adopts GE’s advanced electromagnetic tripping technology, with high-precision overload and short-circuit protection functions.
• Modular Design: The circuit breaker body is separated from the tripping unit, facilitating maintenance and replacement.
• Multiple Safety Protections: Equipped with overload, short-circuit and overheating protection functions.
• Strong Interrupting Capacity: Can quickly cut off current to protect downstream equipment from damage.
• High Adaptability: Supports multiple wiring methods, facilitating on-site installation and wiring.

4. Structure and Composition

• Main Frame: Provides basic mechanical support and installation base.
• Circuit Breaker Body: Includes breaking mechanism, contacts and mechanical structure.
• Tripping Unit: The core component that controls current on-off.
• Connection Terminals: The R2 version includes load lugs and panel connection terminals, facilitating fixed connection of cables.

5. Application Fields

• Industrial Power Distribution: Widely used in distribution panels of industrial buildings to protect large motors, transformers and other equipment.
• Power System: Used for secondary circuit protection of power systems to ensure safe and stable operation of the power grid.
• Automation Control: Used for overload protection in PLC control systems and automated production lines.

6. Installation and Maintenance

Installation

• Panel Installation: Can be directly fixed on standard DIN rails or distribution cabinet panels.
• Wiring: According to the characteristics of the R2 model, ensure that the load cable is correctly connected to the load terminal, and the panel terminal is connected to the power supply side.

Maintenance

• Regular Inspection: Check the contact wear and the tightness of the wiring terminals.
• Replacement: Both the circuit breaker body and the tripping unit are standardized modules, which can be quickly replaced in case of failure.
