GE FBN26TE030R2
1. Overview
GE FBN26TE030R2 is a high/low-voltage circuit protection device based on the GE Record Plus technology platform. Integrating digital control logic and reliable electrical components, it provides precise overcurrent, overvoltage, and leakage protection in various industrial environments. Classified as a “Bolt-On Circuit Breaker”, this model is designed to be directly installed on distribution panels or distribution boxes via bolt fixation, making it suitable for modular power distribution systems.
______________________________________________________________________________________________________
2. Key Specifications
|
Parameter
|
Detailed Value
|
|---|---|
|
Current Rating
|
30 A (Rated Current)
|
|
Poles
|
1 Pole (Single Pole)
|
|
Voltage Grade
|
100 kA @ 277 V (High Breaking Capacity)
|
|
Breaking Capacity
|
100 kA @ 277 V (Corresponding to High Safety)
|
|
Series Model
|
GE Record Plus Series
|
|
Standards
|
Compliant with U.S. NEC and IEC Standards
|
______________________________________________________________________________________________________
3. Product Features
- High Breaking Capacity: With a high breaking capacity of 100 kA, it can quickly cut off current when severe faults (such as short circuits) occur in the power system, preventing fires and equipment damage.
- Modular Design: Adopting the Bolt-On installation method, it is convenient for quick on-site installation or replacement, suitable for efficient maintenance of power distribution systems.
- Durability and Reliability: As a member of the Record Plus series, this product exhibits high reliability in industrial environments, capable of adapting to temperature changes and electromagnetic interference.
- Standardized Dimensions: Compliant with international electrical installation standards (such as IEC), it is easy to be compatible with other GE or third-party electrical components.
______________________________________________________________________________________________________
4. Structure and Composition
- Main Contact System: Responsible for the on-off of current, it is a key component of the device.
- Spring Mechanism: Drives the main contacts to separate quickly when a fault current is detected.
- Operating Mechanism: Controls the closing and opening of the circuit breaker through manual or electric operation.
- Enclosure: Usually a metal enclosure, providing physical protection and protection level.
______________________________________________________________________________________________________
5. Application Areas
- Industrial Power Distribution: Used for power distribution in factories and production lines, protecting key equipment from overload damage.
- Commercial Buildings: Such as the main power distribution systems of large office buildings and shopping malls.
- Energy Systems: Used for the power distribution or secondary control systems of power plants and substations.
- Data Centers: Computer room power supply systems with high reliability requirements.
______________________________________________________________________________________________________
6. Installation and Maintenance
- Installation: Adopt bolt-on installation. Ensure the installation surface is flat and use protective gaskets. During installation, confirm that the load current of the distribution box matches the rated current of the circuit breaker.
- Maintenance: Regularly check whether the operating mechanism is flexible, remove oxides on the contacts, and ensure that the bolt fasteners are not loose. Due to its high breaking capacity, pay attention to the safety distance during maintenance to avoid electric shock.
————————————————————————————————-
