GE DS3800NPSR1A1A
GE DS3800NPSR1A1A is a core circuit board under the Speedtronic Mark IV series (also known as the GE Fanuc 900 series) of General Electric (GE for short). The main function of this board is to provide stable DC power for the system, and it is one of the extremely important “heart” components in the Speedtronic Mark IV series.
______________________________________________________________________________________________
Core Parameters
|
Parameter
|
Description
|
|---|---|
|
Model
|
DS3800NPSR1A1A
|
|
Type
|
Power Supply Card
|
|
Applicable System
|
Speedtronic Mark IV / GE Fanuc 900 Series
|
|
Output Voltage
|
5V/24V DC (specific voltage depends on system configuration)
|
|
Maximum Power
|
1000W
|
|
Power Supply Range
|
180-260VAC (supply voltage)
|
|
Features
|
0.5A output current, 5/48 VDC output, 32 PT (points)
|
|
Terminals
|
Long black connection port at the bottom (marked 10 to 80, interval 10)
|
______________________________________________________________________________________________
Product Features
Stable and Reliable Power Output
Adopting high-quality semiconductor components (such as F28S05/1000Z), it provides a continuous output current of 0.5A, which can effectively drive the PLC host and its external I/O modules.
Easy Maintenance and Fault Diagnosis
The board is equipped with LED indicators (orange LED) and multiple test points, which facilitate on-site engineers to quickly diagnose power supply faults.
Strong Compatibility
This board is a standard component of the Speedtronic Mark IV series, and is widely compatible with various main control boards and I/O modules of the GE Fanuc 900 series.
______________________________________________________________________________________________
Structure and Composition
Semiconductor Power Components
Two black square semiconductors (marked F28S05/1000Z), which are the main power conversion cores.
Capacitor Array
Including capacitors of different specifications (such as C2, C12, C3, C13), which are responsible for smoothing power ripples and transient suppression.
Power Output Port
A long black connection port marked 10, 20, 30…80 is set at the bottom of the board, which is responsible for distributing power to each module.
Auxiliary Components
Including integrated circuits, transistors, LED indicators and multiple test points, which facilitate on-site detection and debugging.
______________________________________________________________________________________________
Application Fields
Power Plants
As the power core of the unit control system (GCU), it provides key power for the main control system.
Industrial Automation
Widely used in the GE Fanuc 900 series DCS system to provide stable power support for the control system.
Other Fields
It may also be used in the control center of large-scale HVAC (Heating, Ventilation and Air Conditioning) systems, as well as other industrial sites that require high-reliability PLC control.
______________________________________________________________________________________________
Maintenance and Common Faults
Cleaning and Dust Removal
After long-term use, dust may accumulate inside the board. The board should be cleaned regularly with a clean soft brush or compressed air to avoid dust affecting heat dissipation.
Component Replacement
If there is unstable power supply or board damage, it is necessary to replace the semiconductor components or capacitors on the board. Due to the involvement of high voltage, replacement must be performed by professional engineers.
————————————————————————————————-
