GE DS303A6A01KXA0
GE DS303A6A01KXA0 is a high-voltage DC contactor specifically designed for DC motor starting and protection. As one of the core products of GE (General Electric) in the field of power systems and industrial automation, it is widely used in generator sets, frequency converters, DC power supply systems and industrial control systems.
______________________________________________________________________________________________
1. Key Technical Parameters
|
Parameter
|
Detailed Specifications
|
|---|---|
|
Rated Operating Voltage (VDC)
|
120 V DC (Coil Voltage)
|
|
Rated Make-and-Break Current (A)
|
600 A
|
|
Rated Operating Voltage (VDC)
|
600 V DC (Contact Voltage)
|
|
Make-and-Break Cycle Life
|
1,000,000 cycles (Standard Life)
|
|
Main Load Capacity
|
High Inductive Load (Suitable for Motor Starting)
|
|
Control Method
|
Mechanical Spring + Electromagnetic Attraction
|
|
Environmental Adaptability
|
Operating Temperature Range: -25°C to 55°C; Protection Class: IP30
|
______________________________________________________________________________________________
2. Core Product Features
High-Voltage DC Special Design
Adopting “closed-loop” arc extinction technology, it can quickly extinguish arc light in high-voltage DC environment and protect system safety.
Electromagnetic Attraction Mechanism
Using GE’s patented electromagnetic attraction mechanism to ensure that the contactor can close reliably even under high load impact.
Shock Resistance
It has strong shock resistance and can maintain stable operation even under the large current impact generated at the moment of motor starting.
Sturdy Structure
Adopting high-strength cast iron or steel shell, it has a compact and durable structure, suitable for harsh industrial environments.
______________________________________________________________________________________________
3. Structure and Composition
Main Contact Group
Responsible for the on-off of the main circuit and directly bearing the motor starting current.
Auxiliary Contact Group
Responsible for the feedback of control signals and used to indicate the contactor status (closed or open).
Coil System
Composed of coil body, magnetic tube and spring, it drives the main contact to close by generating magnetic field when energized.
Insulating Shell
Protects internal electrical components and ensures safe operation.
______________________________________________________________________________________________
4. Typical Application Fields
|
Industry/Field
|
Specific Application Scenarios
|
|---|---|
|
Power Generation Industry
|
Armature circuit and excitation circuit protection of generator sets
|
|
Frequency Converter System
|
Current distribution and cut-off of DC bus
|
|
Industrial Automation
|
Start and stop control of high-power motors
|
|
Rail Transit
|
DC circuit protection of electric vehicle traction system
|
|
Metallurgical Electrolysis
|
Safe cut-off of DC power supply for electrolytic cells
|
————————————————————————————————-
