Ge DS200VPBLG1AEE Bus Backplane Module

GE DS200VPBLG1AEE is a VME bus backplane module under General Electric (GE), mainly used in Load Commutator Inverter Control Systems (LCI). It plays a key role in the field of industrial automation, especially in power systems and gas turbine control systems.

Ge DS200VPBLG1AEE

_______________________________________________________________________________________________________

1. Overview

Full Name: GE DS200VPBLG1AEE VME Backplane Module
Main Function: As the backbone of the VME bus system, it provides physical connection and power distribution, connects various functional modules (such as controllers, sensors, etc.), and realizes data communication and power transmission.
Core Design: Adopts a multi-layer PCB structure, separating the analog power layer from the digital power layer to reduce electromagnetic interference.

_______________________________________________________________________________________________________

2. Parameters & Specifications

Electrical Parameters

Rated Voltage: 24 VDC
Rated Current: 8.3 A
Rated Power: 200 W

Mechanical Parameters

Dimensions: Approximately 230 mm x 165 mm x 40 mm
Weight: Approximately 1.5 kg
Installation Type: Compatible with 13-slot chassis design

_______________________________________________________________________________________________________

3. Product Features

Structural Advantage: Adopts a multi-layer board design, separating analog and digital power planes, which significantly reduces interference and improves signal integrity.
High Reliability: Uses industrial-grade components and high-quality materials, with long service life and stable operation capability.
Modular Design: Structured, easy to install and maintain, facilitating quick replacement and upgrading.
Compatibility: Complies with VME standards and can be compatible with modules from various manufacturers.

_______________________________________________________________________________________________________

4. Structure & Composition

PCB Layout: Includes multiple vertical pin connectors (such as diagnostic 26-pin discrete cable connectors), Mate-n-Lock connectors (for power connection), and 12-pin terminal blocks (for tachometer signals).
Electronic Components: Equipped with resistor network arrays, high-voltage electrolytic capacitors, LED indicators and other components.
Power Management: Bypass capacitors and power distribution functions are provided at each power connection of each slot.

————————————————————————————————-
