1. Overview

2. Parameters

• Power Supply Requirement: Usually adopts 24VDC DC voltage.
• Input Signals: Supports multiple signals such as flame detection, generator/bus voltage, speed and current.
• Output Signals: Signals can be written to TCEB or TCQE boards.
• Operating Temperature Range: -40℃ to 70℃.
• Communication Interface: Supports RS485 communication protocol.

3. Product Features

• Versatility: It can not only be used as a signal terminal module, but also integrates the functions of a power control board, signal expansion module or PAC system component.
• Safety and Durability: It has shock and vibration resistance, suitable for harsh industrial environments.
• Alarm Function: Equipped with J1 jumper, which can enable the buzzer alarm to prompt system abnormalities; removing the jumper can turn off the alarm.
• Modular Design: Compact structure, easy to install and maintain, reducing the number of on-site welding and mechanical installation valves.

4. Structure and Composition

• Terminal Block: With multiple signal lines, responsible for connecting various sensors and actuators.
• Connectors: Including plugs and vertical pin connectors, supporting a variety of special signal connections, such as generator circuit breaker signals, emergency overspeed signals, etc.
• Communication Interface: Supports multiple field bus interfaces, facilitating data interaction with distributed control systems.
• Hardware Specifications: Dimensions are approximately 100mm × 50mm × 25mm, and weight is approximately 500g.

5. Application Fields

• Power System: Used to monitor and protect key parameters such as generators, bus voltage and speed.
• Energy Industry: As part of the Speedtronic turbine control system, it ensures the safe operation of gas and steam turbine systems.
• Industrial Automation: Used in PLC (Programmable Logic Controller) or basic drive cards, suitable for automation scenarios such as robot control and production line control.

6. Installation and Maintenance

• Installation: The design is simple and easy to install, providing complete configuration tools and user manuals for quick configuration and debugging.
• Maintenance: The modular design facilitates on-site maintenance. The manufacturer usually provides a 12-month warranty and quick after-sales support.
• Alarm Setting: During installation, the J1 jumper needs to be set according to on-site requirements to enable or disable the sound and light alarm function of the system.
