1. Product Overview

2. Core Parameters & Specifications

• Model: DS200PCCAG1ACB
• Power Supply: 24V DC
• Communication Interfaces: Supports multiple industrial protocols such as Ethernet, Modbus TCP/IP, and serial communication (e.g., RS232/RS485).
• Physical Dimensions: Approximately 120mm × 80mm × 35mm (specific dimensions may vary slightly by version).
• Temperature Range: -40℃ – +70℃ (industrial-grade temperature resistance range).

_______________________________________________________________________________________________________

3. Product Features

• High-Performance Computing: Equipped with powerful processing capabilities, it can execute complex control algorithms and real-time data processing tasks, meeting the requirements of high-demand industrial applications.
• Redundancy & Reliability: Supports redundant configuration, which can automatically switch in case of unit failure to ensure continuous system operation, especially suitable for critical industries such as power generation.
• Modular Design: Adopts a modular structure, facilitating quick installation, replacement and maintenance, and shortening downtime.
• Flexible Communication: Supports multiple communication protocols, enabling seamless integration into existing industrial networks and systems.

_______________________________________________________________________________________________________

4. Structure & Composition

• CPU Processor: Responsible for core logic computing.
• Memory Module: Used for storing programs and real-time data.
• Communication Interface Board: Realizes network connection with upper computers or other on-site equipment.
• Power Supply Module: Supplies power to the CPU and peripheral devices.

_______________________________________________________________________________________________________

5. Application Fields

• Power Industry: Used in process control systems of power plants (such as boiler control, steam turbine control).
• Petrochemical Industry: Used for automatic control of oil refining and chemical plants.
• Other Industrial Automation: Suitable for industrial scenarios requiring high reliability and real-time control.

_______________________________________________________________________________________________________

6. Installation & Maintenance Recommendations

• Installation Environment: Should be installed in a well-ventilated cabinet, avoiding direct sunlight and high-temperature environments to ensure the temperature is within the rated range.
• Wiring Requirements: Communication cables should use shielded wires to avoid interference; power wiring should comply with industrial standards to ensure good grounding.
• Maintenance Method: It is recommended to regularly check whether the module’s ventilation ports are blocked and clean the dust; regularly back up the control program to prevent data loss.
