Manufacturer:GE

Model Number:DAC 41072001

Module Type:Analog Output Module

Channels:4

Resolution:12-bit

Voltage Range:0-10V

Current Range:0-20mA

Power Supply:24VDC

Operating Temperature:-40°C to +85°C

Protection Rating:IP65

Weight:0.5kg

    The GE DAC 41072001 Analog Output Module is engineered for precision and reliability in industrial environments. It offers four channels of analog output, ensuring that process control systems can transmit signals accurately and consistently.

    This module supports a wide range of signal outputs, including 0-20mA and 4-20mA, making it highly versatile for various industrial applications. The 16-bit resolution ensures that the signal transmission is incredibly precise, minimizing errors and enhancing overall system performance.

    Designed for harsh industrial conditions, the DAC 41072001 has a robust construction with an operating temperature range of -40°C to +85°C. Additionally, it meets NEMA 4 and IP65 standards, providing excellent protection against dust, water, and other environmental factors.

    The power consumption of the module is optimized for efficiency, consuming 100mA at 5VDC and 120mA at 24VDC, making it energy-efficient and cost-effective. This module also boasts high accuracy, with a tolerance of +/- 0.1% of full scale, ensuring reliable and consistent performance over time.

    Installation and maintenance are straightforward thanks to its user-friendly design. The front panel features intuitive controls and indicators, making it easy for operators to monitor and adjust settings as needed. The module is also compatible with existing industrial control systems, ensuring seamless integration and minimal downtime.
