1. Product Overview

2. Core Parameters

• Operating Temperature Range: -20℃ to +70℃ (suitable for harsh outdoor and power plant environments).
• Interface Type: Usually equipped with multi-channel analog or digital interfaces for connecting sensors such as Voltage Transformers (VT) and Current Transformers (CT).
• Communication Protocol: Supports GE’s proprietary communication protocols (such as Rexroth or Modbus) for high-speed data interaction with the main control unit (CPU).

______________________________________________________________________________________________________

3. Product Features

• High-Speed and High-Precision Measurement: It can collect and process key parameters such as stator voltage and current in real time to ensure the generator operates in a stable state.
• Modular Design: Adopts standardized plug-in modules, facilitating quick maintenance and replacement, and minimizing downtime to the greatest extent.
• Strong Anti-Interference Ability: Maintains the integrity and accuracy of data transmission even in high electromagnetic interference environments.

______________________________________________________________________________________________________

4. Structure and Composition

• Input Interface Area: Connects various sensors (such as VT, CT, frequency meter) and is responsible for signal collection.
• Processing Core Area: Integrates a DSP or FPGA chip to perform analog-to-digital conversion (ADC) and digital filtering processing on the collected analog signals.
• Communication Interface Area: Responsible for transmitting the processed data to the excitation controller or upper computer through a high-speed bus (such as PCIe or a proprietary bus).

______________________________________________________________________________________________________

5. Application Fields

• Power Plants: As a core component of the generator excitation system, it ensures the voltage stability of the generator during startup, operation, and load changes.
• Large-Scale Industrial Equipment Control: Used to control high-precision motor drive systems, ensuring the efficient operation of industrial automation.
• Power Grid Stability Control: In power grid dispatching, it provides real-time voltage and current monitoring data to support dynamic regulation of the power grid.

______________________________________________________________________________________________________

6. Installation and Maintenance

• Installation Method: Usually adopts rail mounting (such as 6U or 8U chassis) and connects to the main control unit through the backplane. Strict anti-static measures are required during the installation process.
• Maintenance Strategy: Supports Hot-Swap, which means replacing faulty boards without turning off the system power, minimizing downtime losses to the greatest extent.
• Spare Parts Management: It is recommended to establish an authentic spare parts library to ensure rapid response and recovery when the system fails.
