Communication Baud Rate:300 to 19200 baud

Operating Voltage:220 (V)

Output Frequency:50 (kHz)

Certification:Certified Product

Series:SR750-P5-G5-S5-HI-A20-RT Series

Relay Dimensions:Approx. 18cm W x 16.5cm L x 21.5cm H

Material Coding:SR750-P5-G5-S5-HI-A20-RT

Insulation Voltage:300 V

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Relay Type:Active

Communications Protocol:Modbus RTU or DNP 3.0

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

Operating Environment:Humidity up to 90% non condensing

Environmental Protection Degree:II

    The GE 750-P5-G5-S5-HI-A20-R-E-H Relay is specifically engineered for seamless integration into existing systems, ensuring minimal disruption during installation and maintenance.

    Equipped with advanced communications protocols such as Modbus RTU and DNP 3.0, this relay facilitates efficient data exchange and compatibility with a wide range of industrial automation systems.

    With its high operating voltage and robust insulation, the GE 750-P5-G5-S5-HI-A20-R-E-H Relay is designed to withstand harsh environmental conditions, guaranteeing consistent performance even under extreme circumstances.

    The relay’s dimensions have been optimized for easy installation on standard 19-inch panels, allowing for flexible deployment in various industrial settings without compromising space.

    Featuring versatile input options including phase current, zero sequence current, and sensitive ground current inputs, the GE 750-P5-G5-S5-HI-A20-R-E-H Relay provides comprehensive monitoring and control capabilities for distribution feeder applications.
