Control Power Nominal:20 VA

Control Power Maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:Approximately 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:Class I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Weight:Approximately 4.5 kg

Communication Interfaces:Non-isolated RS232 port, RS485 port

Event Record Triggers:Power fail, alarms, self-test, inhibit, trip, waveform capture

Operating Range:-40°C (-40°F) to +60°C (140°F)

Storage Range:-40°C (-40°F) to +80°C (176°F)

    The GE 369-HI-0-M-0-0 Motor Management Relay is an essential tool for ensuring the reliability and efficiency of your motor systems.

     This relay features waveform capture technology, enabling you to capture detailed information about motor performance and troubleshoot issues more effectively.

     The optional metering package provides comprehensive monitoring capabilities, allowing you to track voltage, current, and other critical parameters in real-time.

     With its robust design and advanced features, the GE 369-HI-0-M-0-0 is ideal for a wide range of industrial applications, including manufacturing, mining, and energy sectors.

     Its compact form factor makes it easy to integrate into existing control systems, and its durable construction ensures reliable operation even in harsh environments.
