GE 2KSC2828F1 NP182557
1. Overview
GE 2KSC2828F1 NP182557 is a high-performance vacuum pump, widely used in high-tech fields such as semiconductors, photovoltaics, and Flat Panel Displays (FPD). Adopting advanced mechanical design and motor technology, this model is designed to provide efficient and stable vacuum pumping capacity.
______________________________________________________________________________________________________
2. Parameters
|
Parameter Category
|
Specific Parameters
|
|---|---|
|
Technical Specifications
|
The vacuum pump is usually equipped with a high-speed rotor design, which can maintain high pumping speed in the low-pressure range.
|
|
Power
|
There may be differences in different configurations, and the common power range is 1kW – 5kW.
|
|
Pumping Speed
|
The specific pumping speed depends on the pump chamber volume and working pressure, and it is usually used in High Vacuum (HV) or Ultra-High Vacuum (UHV) environments.
|
|
Electrical Specifications
|
Supports 220V/380V AC power supply and has overload protection function.
|
|
Material
|
Key components are made of Stainless Steel or Aluminum Alloy, with good corrosion resistance.
|
______________________________________________________________________________________________________
3. Product Features
- Compact Structure: Adopts an integrated design, with a small footprint, easy to install inside equipment or cabinets.
- High Efficiency: Optimized rotor design, high motor efficiency and low energy consumption.
- Low Noise: Good internal structure balance, low noise during operation, suitable for noise-sensitive laboratory environments.
- High Reliability: Guaranteed by GE brand quality, with long service life and low failure rate.
- Easy Maintenance: Modular structure design, easy to disassemble and replace parts.
______________________________________________________________________________________________________
4. Structure and Composition
|
Components
|
Function Description
|
|---|---|
|
Pump Body
|
Composed of pump chamber and bracket, mainly providing physical space for pumping.
|
|
Motor
|
Responsible for driving the rotor to rotate, usually a Brushless Direct Current (BLDC) motor or AC motor.
|
|
Rotor
|
The core component of the vacuum pump, which accelerates the escape of gas molecules through high-speed rotation.
|
|
Bearing
|
Supports the rotor, usually adopts magnetic levitation or ceramic bearings to reduce friction.
|
|
Control Circuit
|
Including electronic components such as power switch, speed regulation, and fault alarm.
|
______________________________________________________________________________________________________
5. Application Fields
- Semiconductor Manufacturing: Used for pumping of equipment such as cleaning machines and lithography machines.
- Flat Panel Display (FPD): Used for vacuum film formation process of glass substrates.
- Photovoltaic Industry: Used for vacuum coating of photovoltaic cells.
- Vacuum Packaging: Vacuum packaging equipment for food and pharmaceuticals.
- Research Experiments: Construction of vacuum environments in physics and chemistry laboratories.
————————————————————————————————-
