GE 193X562AAG06 Relay Board

GE 193X562AAG06 is a general-purpose Relay Board, mainly used to replace the original relay function in GE 193X series drive boards.

GE 193X562AAG06

GE 193X562AAG06 is a general-purpose Relay Board, mainly used to replace the original relay function in GE 193X series drive boards. It is designed to provide additional discrete control points (Relay I/O), allowing users to connect additional relays, switches, or sensors to expand the control capability of the drive system.

______________________________________________________________________________________________

1. Parameters and Technical Specifications

Parameter	Description
Type	General-purpose Relay Board
Number of Relays	6 relays
Contact Form	Each relay provides two C contact pairs (normally open / normally closed)
Coil Voltage	115 VAC (50/60Hz)
Operating Voltage	48 VDC (converted by the on-board rectifier bridge)
LED Indicator	Each relay is equipped with an LED indicator to display its status

______________________________________________________________________________________________

2. Product Features

High Reliability: Complies with GE industrial standards and is designed for harsh industrial environments.
Strong Expandability: Allows users to connect optional external devices as needed, increasing system flexibility.
Easy Integration: Directly installed on the drive board without additional complex wiring.

______________________________________________________________________________________________

3. Structure and Composition

Relay Module: Includes 6 high-voltage-resistant relays, each with a built-in 115 VAC coil.
Rectifier System: On-board rectifier bridge and capacitor, responsible for converting alternating current to direct current and providing 48 VDC operating voltage for the relay coils.
Indicator Lights: Each relay channel is equipped with a corresponding LED indicator to monitor the working status of the relay.

______________________________________________________________________________________________

4. Application Fields

Power System: Used for protection and control of generators, transformers, and power electronic devices.
Machine Tools and Numerical Control: As part of the machine tool spindle or servo system, providing additional discrete control points.
Automation Control: Used in PLC or DCS systems to monitor switch status or control additional loads.

______________________________________________________________________________________________

5. Installation and Maintenance

5.1 Installation

This board is usually directly inserted into the corresponding slot of the GE 193X series drive board or installed via the backplane.
When connecting the power supply, ensure that the input voltage is 115 VAC with a frequency of 50/60Hz.

5.2 Maintenance

Regularly check whether the LED indicators are working normally to determine if the relays are in the normal closed state.
In case of failure, it is recommended that replacement or maintenance be performed by qualified technical personnel to avoid the risk of high-voltage electric shock.

————————————————————————————————-
