Module Type:Analog Voltage Input

Channels:16

Resolution:12-bit

Signal Compatibility:Single-ended

Termination:Common

Operating Voltage Range:VCC

Power Supply:Internal/External

Power Consumption:≤80 mA at 5 VDC

Voltage Output Range:0 to 5 VDC or 0 to 10 VDC

Maximum Output Current:10 mA

Wiring Mechanism:7.62 mm fixed terminal block

    The FACTS F4-16AD-2 is engineered for industrial control systems, offering high precision and reliability in data acquisition tasks. It efficiently converts analog voltage signals into digital formats compatible with PLCs and external devices, ensuring seamless operation in complex automation setups.

    Each of the 16 channels is designed for single-ended connections, terminating into a single common point, which simplifies the wiring process and reduces installation time. The module’s compact design makes it an ideal choice for space-constrained industrial environments.

    Featuring a 12-bit resolution, the FACTS F4-16AD-2 ensures accurate signal conversion, providing the necessary precision for demanding applications. Its wide operating range of 0 to 10V DC accommodates various sensor outputs, making it versatile for different industrial settings.

    The module operates on a minimal power budget, drawing up to 80mA at 5VDC, which significantly reduces energy consumption and helps in maintaining system efficiency. To further enhance energy management, an external power supply ranging from 21.6 to 26.4V DC is required, ensuring reliable performance across a broad operational spectrum.

    Manufactured with durability and reliability in mind, the FACTS F4-16AD-2 is designed to withstand harsh industrial environments. It comes equipped with all the necessary installation and storage guidelines to ensure optimal performance and longevity, contributing to a lower total cost of ownership over its lifecycle.
